Picade
Artwork Template
Console
246 w x 120 h mm
NB. Place artwork so that it extends
over the edges of the template to
allow for any inaccuracies while
cutting (this is known as bleed).
THIS
WAY
UP
3mm
screw
holes
28mm
hole for
joystick
Fits 30mm
buttons
