Picade

Artwork Template

Screen Shim

220 w x 181 h mm

NB. Place artwork so that it

extends over the edges of

the template to allow for

any inaccuracies while cutting

(this is known as bleed).

THIS

WAY

UP

3mm

screw

holes
