USB DrDAQ Programmer's Guide 5
Copyright © 2010-2011 Pico Technology Ltd. All rights reserved. usbdrdaqpg.en
Raw1=2.385
Scaled1=-30
...
Raw32=1.32
Scaled32=100
[Scale2]
Resistor=2.2
LongName=CustomTemperature2
ShortName=TempF
Units=F
MinValue=32
MaxValue=160
...
[Scale3]
Resistor=3.3
LongName=CustomLight
ShortName=Light
Units=lux
MinValue=0
MaxValue=20000
...
The meanings of the terms in the .DDS file are as follows:
[Scale1]
A unique number, from 1 to 99, to identify this entry. (Pico-created numbers are
from 100 upwards.)
Resistor=1
The ID resistor value in kiloohms. In this example "1" represents 1k, "2.2"
represents 2k2 and so on.
For external sensors, this resistor should be fitted in the sensor. You must use one
of the following resistors: 1k0, 2k2, 3k3, 5k6, 7k5 or 10k. The resistor must be 1%
tolerance or better.
For internal sensors, use the following 'virtual' resistor values:
1
Sound Waveform
1200
2
Sound Level
1300
3
Voltage
1500
4
Resistance
1600
5
pH
1400
6
Temperature
1100
7
Light
1000
LongName=Temperature
Used in PicoLog
ShortName=TempC
This field is not used by USB DrDAQ running PicoScope or PicoLog.
Units=C
