UsbDrDaqSetPWM
PICO_STATUS UsbDrDaqSetPWM(
short handle,
USB_DRDAQ_GPIO IOChannel,
unsigned short period,
unsigned char cycle
)
This function is used to configure the general-purpose I/Os as pulse-width modulation
outputs.
Arguments:
handle: handle returned from UsbDrDaqOpenUnit or
UsbDrDaqOpenUnitProgress
IOChannel: GPIOs 1 and 2 can be used as PWM outputs.
period: The period of the waveform in microseconds.
cycle: Duty cycle as a percentage
Returns:
PICO_OK
PICO_NOT_FOUND
PICO_NOT_RESPONDING
PICO_INVALID_PARAMETER
