Appendixes
Specifications
Physical Characteristics
Accessories
CHARGE-PAK Battery Charger
QUIK-PAK Electrode Pads
Height: 10.7 cm (4.2 in)
Width: 20.3 cm (8.0 in)
Depth: 24.1 cm (9.5 in), excluding handle
Weight: 2.0 kg (4.5 lb) with CHARGE-PAK and electrodes
Ty pe : L i /S O
2
Cl
2
Lithium Sulfuryl Chloride, 11.7V, 1.4 amp-hours.
Replacement: Replace after each use or when CHARGE-PAK indicator is visible (typically
after 2 years)
Weight: 80.5 grams (0.18 lb)
Pads: Pacing/defibrillation/ECG electrodes.
Pads Packaging: User-intuitive, rapid-release QUIK-PAK electrodes allow the electrode pads
to be pre-connected to the device and protected under a top cover.
Pads Shelf Life: Two years typical.
Electrode Shape: Oval-rectangular.
Electrode Size: 11.2 cm (4.4 in) × 18.5 cm (7.3 in)
Lead Wire: 1.067 meters (3.5 feet)
Conductive Adhesive
Gel Contact Area:
82 cm
2
(12.8 in
2
)
Maximum Adhesion
Time: 24 hours
Maximum ECG
Monitoring Time: 24 hours
Maximum Number of
Defibrillation Pulses: 50 at 360 joules
Maximum Pacing
Duration: Up to 12 hours
ECG is received from disposable defibrillation electrodes, standard placement (anterior-lateral), or
anterior/posterior placement.
