+ LIFEPAK CR Plus DEFIBRILLATOR LIFEPAK EXPRESS DEFIBRILLATOR ® ® OPERATING INSTRUCTIONS
® LIFEPAK CR Plus DEFIBRILLATOR LIFEPAK EXPRESS DEFIBRILLATOR ® OPERATING INSTRUCTIONS
Responsibility for Information It is the responsibility of our customers to ensure that the appropriate person(s) who may use this defibrillator have access to the information in this manual, including general safety information provided in Section 1. !USA Rx Only Device Tracking !USA The U.S. Food and Drug Administration requires defibrillator manufacturers and distributors to track the location of their defibrillators.
TABLE OF CONTENTS 1 1 Introduction About Automatic External Defibrillators ............................................................................................... 1-2 Indications for Use........................................................................................................................ 1-2 Contraindications ......................................................................................................................... 1-2 Why the Need for Defibrillators ...............
4 Data Storage Overview of Data Storage .................................................................................................................... 4-2 Data Stored by Your Defibrillator .................................................................................................. 4-2 Test and Service Data .................................................................................................................. 4-2 Event and Test Log.......................................................
1 Introduction INTRODUCTION 1 This section provides background information about defibrillation and includes an overview of LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillator features. About Automatic External Defibrillators page 1-2 Safety Information 1-4 Symbols 1-6 About the LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillators LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Introduction ABOUT AUTOMATIC EXTERNAL DEFIBRILLATORS The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are automated external defibrillators (AEDs). For many years, defibrillators have been used only by medical professionals to treat victims in sudden cardiac arrest (SCA). Today, the ability of defibrillators to save lives is so widely recognized that people once trained to do only cardiopulmonary resuscitation (CPR) can now use defibrillators.
Introduction 1 Introduction Terminology The following terms appear in this manual. AED Automated External Defibrillator. A device that evaluates the victim’s heart rhythm and delivers an electrical shock to the heart if a shockable rhythm is detected. Cardiac arrest The termination of the heart’s pumping action resulting in the lack of a heartbeat or pulse and breathing. CPR Cardiopulmonary resuscitation. This involves delivering rescue breathing and chest compressions to a victim in cardiac arrest.
Introduction Text Conventions Throughout this manual, special text characters are used to indicate labels and voice instructions: Operating control labels: CAPITAL LETTERS such as ON/OFF and SHOCK. Voice instructions: ITALICIZED CAPITAL LETTERS such as STAND CLEAR. SAFETY INFORMATION This section provides important information to help you safely operate your defibrillator. Familiarize yourself with all of the terms, warnings, and symbols presented in this section.
Introduction 1 Introduction General Warnings and Cautions WARNINGS! Shock hazard. The defibrillator delivers up to 360 joules of electrical energy. Unless properly used as described in this manual, this electrical energy may cause serious injury or death. Do not attempt to operate this defibrillator unless thoroughly familiar with this manual and the function of all controls, indicators, connectors, and accessories.
Introduction WARNINGS! Possible improper device performance. Using other manufacturers’ cables or electrodes may cause the defibrillator to perform improperly and invalidates the safety agency certification. Use only the parts and accessories specified in this manual. Using damaged or expired equipment or accessories may cause the defibrillator to perform improperly and may injure the victim or the user. Safety risk and possible equipment damage.
Introduction 1 Introduction SYMBOLS The following symbols may appear in this manual and on the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators. For more information about the readiness display symbols, refer to Section 2, "Getting Started". Symbol OK Explanation OK Indicator. The defibrillator is ready for use. Attention. On the readiness display—the internal battery is low. Refer to page 2-4 for more information about the readiness display. Attention.
Introduction Symbol Explanation Not intended for use on children who are less than eight years of age or who weigh less than 25 kg (55 lb). Infant/Child Reduced Energy Electrodes are not compatible with QUIK-COMBO defibrillation and therapy cables. To use Infant/Child Electrodes, connect Infant/Child Electrodes directly to the AED. Not intended for use on adults. Physio-Control electrodes are latex-free. Arrow indicates ON/OFF button location.
Introduction 1 Introduction Symbol Explanation !USA For USA audiences only. Atmospheric pressure limitation. Relative humidity range 5% to 95%. 35°C 50°C 122°F 95°F 15°C 0°C 59°F 32°F Store in a cool, dry location (0° to 50°C or 32° to 122°F). Recommended storage temperature: 15° to 35°C (59° to 95°F). Storage at extreme temperatures of -40° or 70°C (-40° or 158°F) is limited to seven days. If storage at these temperatures exceeds one week, the electrode shelf-life will be reduced.
Introduction ABOUT THE LIFEPAK CR PLUS AND LIFEPAK EXPRESS DEFIBRILLATORS The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are designed for indoor and outdoor use. Each has two models available—fully automatic and semiautomatic. After the electrode pads are applied, the fully automatic model evaluates the heart rhythm and, if a shockable rhythm is detected, delivers a shock without any responder assistance.
Introduction 1 Introduction Defibrillation Electrodes (Pads) When applied to the victim, Physio-Control QUIK-PAK defibrillation electrodes (pads) work with the defibrillator to monitor the heart rhythm and identify when a shock should be delivered. If victim care is transferred to emergency medical personnel, these electrode pads can be disconnected from the defibrillator and reconnected to other AEDs or defibrillators that are compatible with QUIK-COMBO® electrodes.
GETTING STARTED 2 2 Getting Started This section provides an orientation to the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators and describes how to prepare the defibrillator for use. Unpacking and Inspecting Your LIFEPAK CR Plus or LIFEPAK EXPRESS Defibrillator page 2-2 Where to Locate Your LIFEPAK CR Plus or LIFEPAK EXPRESS Defibrillator 2-3 Controls, Indicators, and Labels 2-4 LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Getting Started UNPACKING AND INSPECTING YOUR LIFEPAK CR PLUS OR LIFEPAK EXPRESS DEFIBRILLATOR To help ensure the integrity of your defibrillator and to verify that it is complete, perform the initial inspection as follows: 1 Remove your defibrillator and examine the outside for signs of damage that may have occurred during shipping. 2 Check the remaining contents in the box against the sales order. 3 View the OK symbol in the readiness display. This indicates your defibrillator is ready for use.
Getting Started WHERE TO LOCATE YOUR LIFEPAK CR PLUS OR LIFEPAK EXPRESS DEFIBRILLATOR The defibrillator should be easy to reach in a location free of obstacles. This could include a location near existing emergency equipment, such as fire extinguishers and first-aid kits. When considering location, avoid areas that expose the defibrillator to moisture, dust, or extreme temperatures. Recommended storage temperature is 15° to 35°C (59° to 95°F).
Getting Started CONTROLS, INDICATORS, AND LABELS This section introduces you to the controls, indicators, and labels on the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators. Outside Controls, Indicators, and Labels Controls, indicators, and labels on the outside of the defibrillator are identified in Figure 2-1 and described in Table 2-1.
Getting Started Table 2-1 Outside Controls, Indicators, and Labels (Continued) Feature Description CHARGE-PAK battery The CHARGE-PAK battery charger delivers a trickle charge to the internal charger battery. The battery charger can provide a charge for approximately two years, as long as the defibrillator is not used. The Infrared Data Association defines specifications for infrared wireless communications.
Getting Started Table 2-2 Inside Features Feature Description Quick reference card This card provides abbreviated graphic directions for using your defibrillator to treat a victim in cardiac arrest. Use By date Use By date shown (yyyy-mm-dd) can be viewed through the defibrillator lid when it is closed. Electrode packet The QUIK-PAK electrode packet is preconnected to the defibrillator. This packet contains a set of electrode pads.
Getting Started Table 2-3 Inside Features After Releasing the QUIK-PAK Electrode Packet Feature Description Speaker This projects the voice instructions that lead you through the defibrillation process. Electrode indicators The electrode indicators flash red until the pads are applied to the victim’s exposed chest. When the pads are successfully applied, the indicators turn solid green and the defibrillator can perform an analysis.
USING THE DEFIBRILLATOR 3 This section provides information and instructions for using the LIFEPAK CR Plus or LIFEPAK EXPRESS defibrillator on a victim in cardiac arrest. Warnings and Cautions page 3-2 3-2 Voice Instructions and Tones 3-5 Troubleshooting 3-6 LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Using the Defibrillator WARNINGS AND CAUTIONS To help ensure safe use of the defibrillator, completely familiarize yourself with the following warnings and cautions. WARNINGS! Incorrect rhythm interpretation. Performing CPR or otherwise handling or transporting the victim while the defibrillator is evaluating the heart rhythm can cause an incorrect or delayed diagnosis. Keep the victim as still as possible while the defibrillator is attached and do not transport the victim. Shock hazard.
Using the Defibrillator Basic Steps for Using the LIFEPAK CR Plus or LIFEPAK EXPRESS Defibrillator Responding to an SCA emergency using the defibrillator involves these basic steps: Determine if the victim is in SCA. A person in SCA will not respond when you try to shake him or her. Check for breathing by listening next to the victim’s mouth and looking for chest movement. Use your defibrillator only if the victim is not responding, not moving, and not breathing normally or not breathing at all.
Using the Defibrillator Separate the electrode pads, one at a time, from the blue plastic. Use these pads on adults or children 8 years of age or more, who weigh 25 kg (55 lb) or more. For infants or children who are less than 8 years of age or who weigh less than 25 kg (55 lb), special electrodes are needed. Refer to page 5-8 for more information.
Using the Defibrillator What to Do After Emergency Medical Personnel Arrive When emergency medical personnel arrive, tell them what actions you have taken. Tell them how long the victim has been unconscious, if you delivered shocks, the number of shocks delivered, and if you performed CPR. Do not worry if you cannot recall precisely what happened. Your defibrillator makes a digital recording of heart rhythms and shocks that can be transferred to a computer at a later time.
Using the Defibrillator TROUBLESHOOTING This section explains problems you may encounter while using the LIFEPAK CR Plus or LIFEPAK EXPRESS defibrillator. For information about keeping your defibrillator in a state of readiness, refer to Section 5. Table 3-1 Troubleshooting During Victim Use Problem Possible Cause CHECK PADS FOR GOOD CONTACT or CHECK CONNECTOR voice Inadequate connection to the defibrillator • Be sure that the connector is completely inserted.
Using the Defibrillator Table 3-1 Troubleshooting During Victim Use (Continued) Possible Cause What To Do Defibrillator does not deliver voice instructions or beeping tones after you open it (turn it on) Depleted internal battery • Administer CPR if the victim is not responding, not breathing normally, or not moving. • Replace the CHARGE-PAK battery charger as soon as possible. After the OK symbol appears on the readiness display, return the defibrillator to service.
4 Data Storage DATA STORAGE 4 This section describes the data that the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators store when used in an SCA event. This manual does not provide instructions for how to hand off defibrillation data to the emergency medical system or hospital personnel. Because this process varies from area to area, check with the emergency medical system administration for information and directions.
Data Storage OVERVIEW OF DATA STORAGE Each time you use the LIFEPAK CR Plus or LIFEPAK EXPRESS defibrillator, it digitally saves data about the victim that can be transferred to a PC. This data can be provided to emergency medical personnel or hospital personnel to aid in case review for quality control, training, and research purposes. We recommend that you become familiar with their local requirements for reporting a use of the defibrillator and for providing use data.
Data Storage 4 Data Storage Event and Test Log Table 4-3 lists the types of events that may be annotated on event and test log reports.
CARING FOR YOUR DEFIBRILLATOR 5 Maintaining a State of Readiness page 5-2 Replacing the CHARGE-PAK Battery Charger and the QUIK-PAK Electrode Packet 5-2 Cleaning Your Defibrillator 5-7 Storing Your Defibrillator 5-7 Recycling Information 5-8 Supplies, Accessories, and Training Tools 5-8 Warranty Information 5-8 LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Caring for Your Defibrillator MAINTAINING A STATE OF READINESS Your LIFEPAK CR Plus or LIFEPAK EXPRESS defibrillator does not require routine maintenance. It performs an automatic self-test once a week and every time you turn it on. The electrode indicators briefly flash during the test.
Caring for Your Defibrillator The replacement kit includes a CHARGE-PAK battery charger, one or two QUIK-PAK electrode packets, and a CHARGE-PAK battery discharger. The discharger depletes a used battery charger so that it is ready for recycling or disposal. Note: Always keep the CHARGE-PAK battery charger with its original defibrillator. When a CHARGE-PAK battery charger is inserted into a defibrillator, it becomes internally linked to that device.
Caring for Your Defibrillator Replacing the CHARGE-PAK Battery Charger To replace the CHARGE-PAK Battery Charger: 1 Press the release latch (in the direction of the arrow) to remove the used battery charger. The battery charger springs outward from the defibrillator. 2 Insert the new battery charger into your defibrillator and push until you hear it click into position. 3 Confirm that the symbol disappears and that the OK symbol appears in the readiness display.
Caring for Your Defibrillator To discharge and dispose of a used battery charger: 1 Insert the discharger into the used battery charger. Note: Do not attempt to remove the discharger once it is in place. 5 Caring for Your Defibrillator 2 Let the discharger fully deplete the battery charger. Wait at least 9 days. 3 Place the used battery charger in the trash or recycle it. LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Caring for Your Defibrillator Replacing the QUIK-PAK Electrode Packet To replace the QUIK-PAK Electrode Packet: 1 Press the ON/OFF button to open the defibrillator lid (voice instructions will sound). 2 Press and hold down the ON/OFF button for 2 seconds to turn off the defibrillator and save battery power. a 3 Remove the outdated or used electrode packet: c a Unplug the electrode connector from the connector receptacle. b Slide the anchor pin from the slot.
Caring for Your Defibrillator STORING YOUR DEFIBRILLATOR Always store your defibrillator according to the temperature ranges recommended in Appendix A, "Specifications". WARNING! Possible fire or explosion. Do not store this defibrillator in the presence of flammable gases or in direct contact with flammable material. 5 Caring for Your Defibrillator CLEANING YOUR DEFIBRILLATOR CAUTION! Possible equipment damage.
Caring for Your Defibrillator OBTAINING AUTHORIZED SERVICE WARNING! Shock hazard. Do not disassemble the defibrillator. It contains no operator-serviceable components and dangerous high voltages may be present. Contact authorized service personnel for repair. The WRENCH indicator appears on the readiness display if the defibrillator requires service. Contact authorized service personnel only. In the USA, contact Physio-Control at 1.800.442.1142.
DEFIBRILLATOR OPERATING SETTINGS 6 This section introduces the operating settings that are adjustable on the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators. Operating Settings and Setup Configuration page 6-2 6 Defibrillator Operating Settings LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Defibrillator Operating Settings OPERATING SETTINGS AND SETUP CONFIGURATION The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators have several operating settings. The settings range from defining the time and date used by the defibrillator, to the energy sequence and protocol of the shocks delivered. This group of operating settings are the defibrillator’s setup configuration.
Defibrillator Operating Settings Table 6-1 Operating Settings (Continued) Operating Settings Description Default Setting Device Date The device date and device time are used to time stamp patient reports and to control when the automatic self tests are performed. The date and time can be set when you retrieve data from the defibrillator.
Defibrillator Operating Settings Table 6-1 Operating Settings (Continued) Operating Settings Description Default Setting Time Zone This setting sets the time zone for the location of the defibrillator. Choices are 74 time zones with universal time code (UTC).
Appendixes APPENDIX A SPECIFICATIONS LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Specifications Appendixes SPECIFICATIONS All specifications are at 20°C (68°F) unless otherwise stated. Defibrillator Waveform: Biphasic Truncated Exponential, with voltage and duration compensation for patient impedance. See Figure A-2, "Biphasic Waveform". Patient Impedance Range: 7–300 ohms. If the detected impedance is outside this range, defibrillation is inhibited and the user is prompted to connect electrodes. The following specifications apply from 25 to 175 ohms.
Specifications Waveform Parameters: I1 T1 I2 Patient Impedance () I1 (A) I2 (A) I4 T2 I3 I3 (A) I4 (A) T1 (ms) T2 (ms) 25 69.5 28.3 28.3 15.5 5.6 3.7 50 37.9 19.8 19.8 12.8 7.4 4.9 75 26.1 15.6 15.6 11.0 8.5 5.7 100 19.9 12.7 12.7 9.4 9.7 6.5 125 16.0 10.9 10.9 8.4 10.4 6.9 150 13.5 9.5 9.5 7.6 11.0 7.4 175 11.6 8.5 8.5 6.9 11.6 7.7 Note: Table values are nominal for a 360 joule energy setting.
Specifications Appendixes Charge Ready Time: Timing Parameter 200 Joules 360 Joules Comments Analysis time Less than 10 Less than 10 Analysis time applies if no seconds seconds motion is detected. If the device detects motion, analysis may be delayed by up to 10 seconds.
Specifications User Interface User Interface: The user interface includes voice instructions, audible tones, and graphical prompts. Readiness Display The readiness display shows the device status. OK Indicator: Indicates OK when the last self test was completed successfully. When the OK indicator is visible, all other indicators are not visible. The OK indicator is not displayed during device operation. CHARGE-PAK Indicator: When displayed, replace the CHARGE-PAK battery charger.
Specifications Appendixes Physical Characteristics Height: 10.7 cm (4.2 in) Width: 20.3 cm (8.0 in) Depth: 24.1 cm (9.5 in), excluding handle Weight: 2.0 kg (4.5 lb) with CHARGE-PAK and electrodes Accessories CHARGE-PAK Battery Charger Type: Li/SO2Cl2 Lithium Sulfuryl Chloride, 11.7V, 1.4 amp-hours. Replacement: Replace after each use or when CHARGE-PAK indicator is visible (typically after 2 years) Weight: 80.5 grams (0.
Specifications Data Storage Memory Type: Internal digital memory. ECG Storage: Dual victim Data Storage. Minimum 20 minutes of ECG stored for the current victim. Summarized data stored for the previous victim. Report Types: Continuous ECG—A continuous ECG report for the victim. Summary—A summary of critical resuscitation events and ECG waveform segments associated with these events. Event Log report—A report of time stamped markers, which reflect operator and device activity.
Specifications Appendixes CLINICAL SUMMARY: DEFIBRILLATION OF VENTRICULAR FIBRILLATION AND VENTRICULAR TACHYCARDIA Background Physio-Control conducted a multi-centered, prospective, randomized and blinded clinical trial of biphasic truncated exponential (BTE) shocks and conventional monophasic damped sine wave (MDS) shocks. Specifically, the equivalence of 200 J and 130 J BTE shocks to 200 J MDS shocks1 was tested.
Specifications Shock Ventricular Fibrillation 1st Shock Success Exact 95% Confidence Interval 200 J MDS 26/28 (93%) 77 to 99% 200 J BTE 22/23 (96%) 78 to 100% 130 J MDS 20/21 (95%) 77 to 100% Conclusions In this double-blinded study, the efficacy of the 200 J BTE shocks was demonstrated to be at least equivalent to the efficacy of 200 J MDS shocks for defibrillation of short duration, electrically-induced VF.
Appendixes APPENDIX B SHOCK ADVISORY SYSTEM LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Shock Advisory System Appendixes OVERVIEW OF THE SHOCK ADVISORY SYSTEM The Shock Advisory System (SAS) is an ECG analysis system built into the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators that advises the operator if it detects a shockable or nonshockable rhythm. This system makes it possible for individuals not trained to interpret ECG rhythms to provide potentially-lifesaving therapy to victims of ventricular fibrillation or pulseless ventricular tachycardia.
Shock Advisory System Table B-1 LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator SAS Performance Table for Adult ECGs (Continued) ECG Test1 Sample Size Performance Goal2, 3 Observed Performance Sensitivity or Specificity [LCL]4 Nonshockable: all other rhythms 531 >95% specificity 95.9% [94.5%] Intermediate: fine VF 29 Report only 96.6% [87.2%] sensitivity Rhythm Class 1 From Physio-Control ECG database. Each sample is run 10 times asynchronously.
Shock Advisory System Appendixes Table B-3 LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator SAS Performance Table for Pediatric ECGs (Continued) ECG Test1 Sample Size Performance Goal2 Observed Performance Sensitivity or Specificity [LCL]3 Nonshockable: all other rhythms 433 >95% specificity 99.3% [98.5%] Intermediate: fine VF 4 Report only 100.0% [56.2%] sensitivity Intermediate: other VT 7 Report only 42.9% [17.0%] specificity Rhythm Class 1 From Physio-Control ECG database.
Appendixes APPENDIX C USER’S CHECKLIST This User’s Checklist may be reproduced. LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Appendixes LIFEPAK CR® PLUS LIFEPAK EXPRESS® DEFIBRILLATOR USER’S CHECKLIST Unit Serial Number _________________________ Department/Location _______________________ Date Instruction 1 Recommended Corrective Action Initials Check readiness display for: OK indicator None. CHARGE-PAK indicator Replace CHARGE-PAK™ Battery Charger and QUIK-PAK™ Electrode Packet. ATTENTION indicator Refer to operating instructions. WRENCH indicator Contact authorized service personnel.
Appendixes D APPENDIX D ELECTROMAGNETIC COMPATIBILITY GUIDANCE LIFEPAK CR Plus and LIFEPAK EXPRESS Defibrillator Operating Instructions ©2009-2010 Physio-Control, Inc.
Electromagnetic Compatibility Guidance Appendixes Table D-1 Guidance and Manufacturer’s Declaration – Electromagnetic Emissions Guidance and Manufacturer’s Declaration – Electromagnetic Emissions The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are intended for use in the electromagnetic environment specified below. The customer or the user of the defibrillator should ensure that the defibrillator is used in such an environment.
Electromagnetic Compatibility Guidance Table D-2 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are intended for use in the electromagnetic environment specified below. The customer or the user of the defibrillator should ensure that the defibrillator is used in such an environment.
Electromagnetic Compatibility Guidance Appendixes Table D-3 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity Guidance and Manufacturer’s Declaration – Electromagnetic Immunity Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment – Guidance The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are intended for use in the electromagnetic environment specified below.
Electromagnetic Compatibility Guidance Table D-4 Recommended Separation Distances between Portable and Mobile RF Communications Equipment and the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators Recommended Separation Distances between Portable and Mobile RF Communications Equipment and the LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators The LIFEPAK CR Plus and LIFEPAK EXPRESS defibrillators are intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
INDEX Index A About Automatic External Defibrillators 1-2 About the Defibrillators 1-10 Accessories 5-8 ADAPTIV 1-10, 1-11 AED 1-2, 1-3 Attention Indicator 2-4, 5-2 B Basic Steps 3-3 Blue Plastic 2-6, 2-7 C Cardiac Arrest 1-3 Caring for the Defibrillator 5-1 Carrying Handle 2-4, 2-5 CHARGE-PAK 1-10, 2-4, 2-5 CHARGE-PAK Indicator 2-4, 5-2 Cleaning Methods 5-7 Cleaning the Defibrillator 5-7 Clinical Summary A-7 Continuous ECG 4-2 Controls 2-4 CPR 1-3 CPR Time 6-2 D Data Storage 4-2 Data Storage Characteristi
Index Capabilities and Features 1-10 Customized Setup 1-10 Data Management 1-10 Defibrillation Electrodes 1-11 Defibrillation Waveform 1-11 Heart Rhythm Analysis 1-11 Operator Settings Motion Detection 1-11 Power System 1-11 Readiness Display 1-11 Troubleshooting 3-6 Log Reports 4-3 M Maintaining a State of Readiness 5-2 Managing Data 4-1 Motion Detected 3-6 Motion Detection 6-3 Myocardial Infarction 1-3 N Nonshockable Rhythm 1-3 O Obtaining Authorized Service 5-8 OK Indicator 2-4, 5-2 ON-OFF Button 2-4 Op
Physio-Control, Inc. 11811 Willows Road NE Redmond, WA 98052 USA Telephone: 425.867.4000 Toll Free (USA only): 800.442.1142 Fax: 425.867.4121 www.physio-control.com Physio-Control Australia Medtronic Australasia Pty Ltd 97 Waterloo Road North Ryde, NSW 2113 Physio-Control, Inc., 11811 Willows Road NE, Redmond, WA 98052 USA Medtronic B.V.
