Register your product and get support at www.philips.
1 Important 4 Safety 4 Recycling 4 2 Your SDV5120 Overview 5 5 3 Get started 5 Installation 5 4 Set up SDV5120 English Contents 6 For VHF/FM reception 6 For UHF reception 7 Set up a digital tuner with this antenna 7 5 Frequently asked questions 8 6 Warranty and service 8 7 Glossary 9 EN 3
1 Important Safety This manual contains important information about the Philips indoor television antenna. Read it carefully before you start the installation and setup. Recycling Your product is designed and manufactured with high quality materials and components, which can be recycled and reused. When you see the crossed-out wheel bin symbol attached to a product, it means the product is covered by the European Directive 2002/96/EC: Never dispose of your product with other household waste.
Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips. com/welcome.
Connect to the TV 1 2 3 One end of the coaxial cable is already connected to the signal output of the antenna. 4 Set up SDV5120 Connect the other end to the input on the TV receiver. For VHF/FM reception 1 Extend the telescopic dipoles to the longest Connect the DC plug to the antenna and the power supply to a 230-240V AC outlet. 2 possible length. Turn the TV or FM radio to the desired channel/station. Move the dipoles in different directions up and down until the reception is achieved.
English Note •• It is possible to turn the gain control knob down for best reception. For UHF reception 1 2 Turn the TV to the desired channel/ station. To turn the amplifier up, rotate the gain control knob towards the max position. Note •• It is possible to turn the gain control knob down for best reception. Set up a digital tuner with this antenna 3 Tilt or swivel the UHF loop antenna towards the transmitter until the reception is achieved.
5 Frequently asked questions Can this antenna work with Analogue transmissions? Yes, this antenna can receive analogue television broadcasts in the UHF and VHF bandwidths. Can this antenna receive digital or work with HD-DVB broadcasts? Yes, this antenna is designed to receive digital DVB and HDTV broadcasts in the UHF & VHF bandwidths. Can the antenna be powered by a DC power supply in a boat, RV or camper? Yes, there is a DC power socket located at the back of the antenna.
A Amplifier A device, either a single stage or a large scale circuit with multiple stages for creating gain, i.e. it makes small signals larger. Antenna A device, such as a rod or wire, which picks up a received radio frequency signal or radiates a transmitted RF signal. C Coaxial A single copper conductor, surrounded with a layer of insulation, covered by a surrounding copper shield and finally, an insulating jacket. An unbalanced transmission line with constant impedance.
© 2008 Koninklijke Philips Electronics N.V. All rights reserved.
