Español Française User Manual 26PF5321D/37 32PF5321D/37 32PF7321D/37 37PF7321D/37 42PF5321D/37 42PF7321D/37 42PF7421D/37 50PF7321D/37 English LCD / Plasma HDTV 3139 125 35242 LC06D (and Model / Serial number) Model No.: Serial No.: cover.
Return your Warranty Registration card today to ensure you receive all the benefits you’re entitled to Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don’t miss out.
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment 1. 2. 3. 4. 5. 6. 7. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.
Contents Care of the screen See Tips, p. 28. R End of life directives Philips is paying a lot of attention to produce environmentally-friendly products in green focal areas. Your new TV contains materials which can be recycled and reused. At the end of its life specialized companies can dismantle the discarded TV to concentrate the reusable materials and to minimize the amount of materials to be disposed off. Please ensure you dispose off your old TV according to local regulations.
A Guide to Digital TV What is Digital Television (DTV)? Digital Television (DTV) is relatively new type of broadcasting that promises to transform television viewing into a whole new experience. Digital technology is used to capture images and sound to deliver a better picture quality. DTV technology is also capable of multicasting and interactive capabilities. There are many levels of digital television quality.
ACE & Basic connections to the TV Your integrated digital TV automatically decodes and displays the four basic DTV picture resolution standards. - SDTV (Standard Definition TV) are broadcast as 480i (480-line interlaced) or 480p (480-line progressive scan) video. - HDTV (High-Definition TV) are broadcast either in the 1080i or 720p formats, always with a widescreen picture. Note: Progressive scan video (p) is more like that you see in a movie theater.
- Cable box with S-Video, component video (YPbPr) or HDMI connectors See Connect Accessory Devices, p. 22-23. - Antenna Via antenna you can watch whatever DTV programs being broadcast in your area for free. If you’re not sure what HDTV programming is available in your area, contact your local content provider or your local electronics store retailer. Broadcasters are in the middle of a transition from analog to digital TV.
Use of the remote control Note: For most buttons pressing a button once will activate the function. Pressing a second time will de-activate it. When a button enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list. The list will be removed automatically after 6 seconds or press OK to remove immediately. DVD/R CBL TV VCR AUX Press the SELECT button repeatedly to select POWER one of the system modes in which the remote control can be used.
FORMAT Press this button to summon a list of available display formats (depending on the receiving signal). This lets you choose the display format of your preference. Press this button repeatedly to select another picture format: Automatic, Super Zoom, 4:3, Movie expand 14:9, Movie expand 16:9, 16:9 subtitle, Wide screen. Automatic Super zoom 4:3 Movie expand 16:9 16:9 subtitle Wide screen Movie expand 14:9 Automatic makes the picture fill the screen as much as possible.
My Content The My Content menu (and the underlying Multimedia browser) is intended to contain all content, services, applications you are interested to consume. & Press the button to activate. é Press the cursor up/down to move the highlight up and down in the list of menu items. “ Press the cursor right to go deeper into the structure.
Demo The Demo menu allows the user to get an idea of the features that are part of the television. & Select Demo in the Settings menu and press the cursor right. é Highlight a desired demo with the cursor up/down. “ Press OK to start playing the highlighted demo. Press the green color button to automatically run all demos in sequence. Press the red color button to stop the auto run function. Press the red color button again to exit the demo and to return to TV mode. Note: The selected demo is played once.
Channel tuning Available channels: - Cable (analog NTSC or digital QAM): max. from 1 to 135 - Antenna (analog NTSC or digital ATSC): max. from 2 to 69 If a tuned channel is not yet in the master channel map, the TV will attempt to tune the channel and it will be added to the map. If the channel is not acquired, a message will appear that the channel is not available. When you tune an audio-only digital subchannel, a display appears with the message Audio only.
Setup menu This menu is used to control the settings of special TV functions, features and accessory devices. The Preferences menu allows you to change settings that will typically be accessed only occasionally. The Source menu allows you to select a source. The Clock menu allows you to use your TV as a clock. This setup is necessary for the correct working of the Lock after feature. Preferences & Press the MENU button.
& Select Captions service. é Press the cursor right. Note: The captions do not always use correct spelling and grammar. Not all TV programs and product commercials are made for broadcast with Closed Caption informations included. Refer to your area’s TV program listings for the TV channels and times of Closed Caption shows. The captioned programs are usually noted in the TV listings with service marks such as ‘CC’.
Menu preferences OSD & Select OSD. é Press the cursor right to select Normal or Minimum. Normal to activate the continuous display of the channel number (for max. 10 minutes) and extended display of TV channel and program information on screen. E.g. information on the main or auxiliary program, input signal quality of connected accessory devices, the display format, sound mode, availability of Closed Caption service, the audio language, the rating, sleeptimer setup.
Source This menu allows you to identify the accessory devices you have connected to the external inputs/outputs. & Select Source in the Setup menu. é Press the cursor right to enter the list of types of devices connected to the selected input. “ Select the accessory device with the cursor up/down. When you select AV1, AV2, AV3, HDMI, Side or Analog Audio In, a list appears allowing you to identify which type of accessory device is attached to this input.
TV menu Press the MENU button on the remote control to summon the Settings menu. The TV menu gives you an overview of the menus you can select. Note: Depending on the input signal, one or more menu items may not be selectable. Picture menu Note: Some menu items are not available in case of HD sources. & Press the cursor right to select Picture. é Press the cursor right again to enter the Picture menu. “ Select the menu items with the cursor up/down.
DNR (Digital Noise Reduction) Automatically filters out and reduces the image noise and improves picture quality when receiving weak video signals. & Press the cursor right to enter the list. é Select Off, Minimum, Medium or Maximum according to the image noise. “ Press the cursor left to return to the picture menu. Color enhancement When activated, this feature automatically controls green enhancement and blue stretch. It makes the colors more vivid. & Press the cursor right.
Headphone volume This controls the level of sound through the headphones. Sound mode This selects the modes for stereo or surround sound reproduction dependent on the broadcast signals or signals from external inputs received. Alternate audio (only selectable with analog broadcast signals) This gives you the possibility to swap between the Main and Second audio Program (SAP) when it is available.
Channels menu This menu can control special functions for the TV channels. & Select Channels in the TV settings menu with the cursor up/down. é Press the cursor right to enter the channels menu. “ Press the cursor up/down to select a channels menu item. Lock after Note: Lock after is only selectable if time is known. See Setup, Clock menu, p. 13. This allows you to prevent the viewing of the channels after a selectable time delay.
TV-Y appropriate for children of all ages with themes and elements suitable for children aged 2-6 TV-Y7 programs designed for children age 7 and older TV-Y7-FV programs include fantasy violence more intense than other programs in the TV-Y7 category TV-G programs suitable for all ages.
Preferred channels A channel, when installed, is marked as preferred by default and added to the channel list. This feature provides the ability to remove a channel number from the channel list. & Select Preferred channels with the cursor down. é Press the cursor right to enter a list with all stored channel numbers. “ Select the channel you want to remove with the cursor down. ‘ Press OK. ( Repeat to remove other channels.
Connect Accessory Devices There is a wide range of audio and video devices that can be connected to your TV. The following connection diagrams show you how to connect them to the TV. AV1 and AV2 can handle YPbPr or VIDEO and L/R Audio, AV3 VIDEO or S-VIDEO and L/R Audio and Digital Audio Out (SPDIF OUT), USB Side VIDEO or S-VIDEO and L/R Audio.
Recorder and cable box with RF output & Use an optional signal splitter. CABLE AUDIO IN é Connect one of the cable TV signal splitter outputs 1 to the cable box’s IN jack. VIDEO IN AV1 “ Connect the other cable TV signal splitter output 2 to the CABLE/ANTENNA 75 Ω x plug on the bottom of the TV. ‘ Connect the cable box’s OUT jack 3 to the recorders RF IN SIGNAL AV1 : L + R + VIDEO SPLITTER 2 socket.
SPDIF OUT YPbPr AUDIO IN VIDEO IN VIDEO IN AUDIO IN AV1 AV2 AV3 VIDEO IN DVD Player or other accessory digital source devices Devices with Component Video Output Connectors (YPbPr) This TV is capable of displaying 1080i, 720p and 480p DTV signals when connected to a DTV tuner Set Top Box. Select the output of the Set Top Box to either 1080i, 720p or 480p. A DTV signal must be available in your area.
HDMI (High Definition Multimedia Interface) connectors HDMI is the leading new standard for Digital video and audio interconnection. To the HDMI connector you can connect HDMI devices such as a Set Top Box or compatible DVD-R or DVD player with HDMI, or DVI-equipped devices like a computer. So you can display high-definition pictures on this TV in the digital form. Note: If the accessory device has DVI output only, use a DVI to HDMI adapter cable to connect to the HDMI connector.
Side connections 37PF7321D 42PF7421D 42PF5321D 42PF7321D 50PF7321D 26PF5321D 32PF5321D 32PF7321D USB 3 2 1 1 2 2 VIDEO IN S-VIDEO IN USB USB 3 3 AUDIO IN 1 Camera, Camcorder, Game & Connect your camera, camcorder or game as shown. é Connect to VIDEO 2 and AUDIO L 3 for mono equipment. For stereo equipment also connect AUDIO R 3. S-VHS quality with an S-VHS camcorder is obtained by connecting the S-VHS cables with the S-VIDEO input 1 and AUDIO inputs 3.
Multimedia Browser menu & Insert a USB device. é Select the USB device under Multimedia with the cursor up/down. “ ‘ ( § è ! ç Notes: • Your TV supports slide shows with background music. See Annex 2, p. 34. • The playback will continue to play even if temporarily switched to browser screens. The audio will be stopped when another song starts playing, or when the end has been reached. • Progressive JPEG files are not supported. • The length of the files should not exceed 128 characters.
¨ MENU PIP + + VOL CH/ MUTE PAGE - - _- ABC DEF 1 2 3 GHI JKL MNO To select connected devices 4 5 6 PQRS TUV WXYZ 7 8 9 .@ CC VIEW - 0 AV+ INFO ACTIVE CONTROL - FAVORITES - & Press the AV+ button repeatedly or select Source in the Settings menu (see p. 13) to select AV1, AV2, AV3, HDMI, Side or TV, according to REC where you connected your devices. 3 é Press the cursor up/down. “ Press OK. Regulatory Notices - Federal Communications Commission Notice rc 4342 av.
Kensington Security Slot (if present) Your TV is equipped with a Kensington Security Slot, to prevent it from getting stolen. An anti-theft Kensington lock has to be purchased separately. The Kensington lock is a plastic-coated steel cable with a lock. One end has to be fixed to the opening of the TV and locked with a special key. The other end is attached to a fixed point.
If your problem is not solved Turn your TV off and then on again once. Never attempt to repair a defective TV yourself. Check with your dealer or call a TV technician. Telephone number Philips Customer Care Center: 1-888-PHILIPS (744-5477) Please, have the Model and Product number which you can find at the back of your television set ready, before calling. Tips Care of the screen Do not touch, push or rub or strike the screen with anything hard as this may scratch, mar or damage the screen permanently.
Glossary DVI (Digital Visual : Interface) A digital interface standard created by the Digital Display Working Group (DDWG) to convert analog signals into digital signals to accommodate both analog and digital monitors. VGA (Video Graphics Array) : a common standard graphics display system for PCs. RGB signals : These are the three video signals, Red Green Blue, which make up the picture. Using these signals improves picture quality.
Specifications PICTURE / DISPLAY Aspect ratio Picture Display Picture Enhancement SOUND Ouput Power (RMS) Sound Enhancement Sound System 26PF5321D 32PF5321D 42PF5321D 32PF7321D 16 : 9 16 : 9 15 : 9 16 : 9 Pixel Plus Progressive Scan 3/2 - 2/2 motion pull down Active Control Auto Picture (6 modes) Color, Contrast, Sharpness Control Pixel Plus Progressive Scan 3/2 - 2/2 motion pull down Active Control Auto Picture (6 modes) Color, Contrast, Sharpness Control Pixel Plus Progressive Scan 3/2 - 2/2
Specifications PICTURE / DISPLAY Aspect ratio Picture Display Picture Enhancement 37PF7321D 42PF7421D 42PF7321D 50PF7321D 16 : 9 16 : 9 15 : 9 16 : 9 Pixel Plus Progressive Scan 3/2 - 2/2 motion pull down Active Control Auto Picture (6 modes) Color, Contrast, Sharpness Control Pixel Plus Progressive Scan 3/2 - 2/2 motion pull down Active Control Auto Picture (6 modes) Color, Contrast, Sharpness Control Pixel Plus Progressive Scan 3/2 - 2/2 motion pull down Active Control Auto Picture (6 modes) C
Annex 1 - Philips TV software upgrade with portable memory Introduction Philips offers software upgrade capability for your TV using USB portable memory. After you have completed a software upgrade, your TV will typically perform better. What improvements are made depends on the upgrade software you are using as well as the software your TV contained before the upgrade. You can execute the software upgrade procedure yourself.
Automatic software upgrade procedure & Power off your TV and remove all memory devices. é Insert the USB portable memory that contains the downloaded software upgrade. “ Switch on your TV with the power switch B at the right side of the TV. ‘ At startup the TV will scan the USB portable memory until it finds the update content. The TV will automatically go to the upgrade mode. After a few seconds it will display the status of the upgrade procedure.
Annex 2 - Philips TV Slideshow Format with background music Notes: - The latest version of this document can be found on the Philips support website (www.philips.com/support). Use the type number of your TV (e.g. 32PF5321D/37) to find this documentation and other related files. - Philips can’t be held responsible for any problems that may occur as a result of the content in this document. Errors reported to Philips will be adapted and published on the Philips support website as soon as possible.
Supported XML-tags The following table gives a description of the XML syntax. Tag Name Use Description philips-slideshow mandatory Philips slideshow signature including the version. title optional The title of the playlist. audio optional The audio-URL following this tag will define the music playing in the background during the slideshow. A single song or playlist (.m3u & .pls) are the only valid audio references. Other reference will not result in any audio playback.
Annex 3 - Philips TV USB Notes: - The latest version of this document can be found on the Philips support website (www.philips.com/support). - The software of your TV is upgradeable. If you have problems first check if you have the latest software installed on your TV. The latest software, together with instructions, can be found on the Philips support website. Use the type number of your TV (e.g. 32PF5321D/37) to find this documentation and other related files.
PHILIPS LIMITED WARRANTY One (1) Year Labor & One (1) Year Parts & One (1) Year Display Repair PHILIPS warrants this product against defect in material or workmanship, subject to any conditions set forth as follows: PROOF OF PURCHASE: You must have proof of the date of purchase to receive repair on the product. A sales receipt or other document showing the product and the date that you purchased the product as well as the authorized retailer included, is considered such proof.
