Dimensions Guide

Dimensions
Speciications
Features
Port Haven™
Pot Filler Kitchen Faucet
GT533TDC Finish(C) q
GT533TDD Finish(D) q
GT533TDS Finish(S) q
GT533TDY Finish(Y) q
• Wall Mount Installation
• Pforever Seal
• Pforever Warranty
• 3.0 GPM Flow Rate
• 1Hole Installation
• All Metal Construction
• 360 Rotating Spout
• Dual Shut O Levers
• Mounting Hardware Included
• Swing Out Design
• Cold Water Installation
Recommended
• Pforever Seal Ceramic
Disc Valve
• Pforever Warranty®
8-1/32
[204.2]
5/16 [8]
2-5/8
[66.5]
5-1/4 [133.4]
3-5/16
[83.8]
2-7/8
[73]
24-13/32 [620]
20-4/32 [511]
13-1/32
[331]
9-15/16
[252.4]
7-3/32
[180]
Copyright © 2019, Pister Inc.
1800PFAUCET (7328238) • pisterfaucets.com/support
Ø13/8 Min to Ø11/2 Max. Deck Hole Openings
SS-GT533-TDX
June 20, 2019
Code Compliance
• IAPMO Certiied
• CSA B125 Certiied
• ASME A112.18.1
• NSF 61/9 & 372 (Low Lead)
• ADA Compliant-ANSI A117.1 (Lever handles only)
Pister products are designed and
manufactured in compliance with the
following standards and codes:
1227210 REV 02
