Technical Data Sheet
Permatex
White Lithium Grease
AAM Revised 10/02
NOT FOR PRODUCT SPECIFICATIONS.
THE TECHNICAL DATA CONTAINED HEREIN ARE INTENDED AS REFERENCE ONLY.
PLEASE CONTACT PERMATEX, INC., TECHNICAL SERVICE DEPARTMENT FOR ASSISTANCE AND RECOMMENDATIONS FOR YOUR SPECIFIC APPLICATION.
PERMATEX, INC., HARTFORD SQUARE NORTH, 10 COLUMBUS BOULEVARD, HARTFORD, CT 06106 PHONE – (1-87PERMATEX)
PRODUCT DESCRIPTION S.I.N.: 834-300
Permatex
White Lithium Grease is a liquid aerosol lubricating
paste designed to reduce friction between load bearing
moving metal surfaces and/or the combination of metal and
plastic surfaces. The product also protects metal surfaces
from corrosion.
PRODUCT BENEFITS
• Multi-purpose, high temperature, long lasting lubricant
• No-sag Teflon based formula increases lubricity
• Easy application, aerosol spray for maximum coverage
• Excellent rust and corrosion inhibitor.
• VOC compliant.
TYPICAL APPLICATIONS
AAM
General purpose lubrication and corrosion protection for:
• Automotive seat slide mechanisms
• Interior window mechanisms
• Windshield Wiper mechanisms
• Door and hood hinges
• Radio antennas
DIRECTIONS FOR USE
1. Provide adequate ventilation.
2. Shake can thoroughly until the ball agitator inside the
can is free. For best results, aerosol can should be at
room temperature before spraying.
3. Holding can 8 to 10 inches from the surface for open
area lubrication, or using the extension tube provided for
hard to reach areas, press the nozzle and discharge the
product on the assembly.
4. Repeat procedure if necessary.
For Cleanup
1. Turn can upside-down and spray to clear nozzle.
2.
Clean hands with Permatex
brand hand cleaners.
PROPERTIES OF MATERIAL
Typical Value
Chemical Type Lithium grease
Appearance White film
Odor Mild
Worked Pentrometer*, ASTM D-217, mm 290 to 310
Dropping Point** ASTM D-566, °C (°F) 193 (380)
Oxidation***, ASTM D-942, psi 5.0 max
Rust 3 Bearing****, ASTM D-1743 1,1,1
Performance temperature range, °C (°F) -10 to 150 (-15 to 300)
Flash Point Aerosol, contents under pressu
r
consult MSDS
NFPA 704 Flammability Rating 4 (Highly flammable)
* Measure of consistency of a grease to determine its plasticity
** The temperature at which a grease turns to a liquid state
*** The resistance of lubricating greases to oxidation
**** Corrosion preventive properties of lubricating greases
GENERAL INFORMATION
This product is not recommended for use in pure oxygen
and/or oxygen rich systems and should not be selected as
a sealant for chlorine or other strong oxidizing materials.
For safe handling information on this product, consult the
Material Safety Data Sheet, (MSDS).
ORDERING INFORMATION
Part Number Container Size
81981 (195DA) 16 oz. aerosol can
80345(WL-9) 1.5 fl.oz.tube, carded
STORAGE
Products shall be ideally stored in a cool, dry location in
unopened containers at a temperature between 8°
to 28°C
(46°
to 82°F) unless otherwise labeled. Optimal storage is at
the lower half of this temperature range.
NOTE
The data contained herein are furnished for information only
and are believed to be reliable. We cannot assume
responsibility for the results obtained by others over whose
methods we have no control. Permatex, Inc. specifically
disclaims all warranties expressed or implied, including
warranties of merchantability or fitness for a particular
purpose, arising from sale or use of Permatex, Inc.
products and disclaims any liability for consequential or
incidental damages of any kind, including lost profits.
This product may be covered by one or more United States or
foreign patents or patent applications.
