Specification Sheet

Technical Data Sheet High Temperature Threadlocker RED
Permatex is a trademark of Permatex, Inc. © 2002 All rights reserved
For Reassembly
1. Remove loose product from nut and bolt.
2. Apply primer to all threads, regardless of metal type.
3. Assemble and tighten as usual.
PROPERTIES OF UNCURED MATERIAL
Typical Value
Chemical Type Anaerobic Dimethacrylate Ester
Appearance Opaque Red-Orange Liquid
Specific Gravity 1.11
Viscosity @ 25
_
C, mPa.s (cP) 4,000 to 15,000
Flash Point (TCC),
_
C (
_
F) >93 (200)
TYPICAL CURING PERFORMANCE
Cure speed vs. substrate
The rate of cure will depend on the material used. Permatex
®
Hi-Temp/Hi Strength Threadlocker RED will react faster and
stronger with Active Metals. However, Inactive Metals will
require the use of a primer (Surface Prep) to obtain maximum
strength and cure speed at room temperature.
Active Metals Inactive Metals
Soft Steel Iron Bright Platings
Copper Anodized Surfaces
Brass Titanium
Manganese Zinc
Bronze Pure Aluminum
Nickel Stainless Steel
Aluminum Alloy Cadmium
Cure speed vs. temperature
The rate of cure will depend on the ambient temperature. Full
cure is attainable in 24 hours at room temperature, 22°C
(72°F), or 1 hour at 93°C (200°F).
Cure speed vs. primer
To shorten cure time or if an inactive surface is present,
applying a primer (Surface Prep) to the surface will improve
cure speed. A 3/8-16 steel nut and bolt assembly will fixture in
5 minutes using a primer, while fixturing will occur in 20
minutes without a primer. Full cure in 24 hours for both
procedures.
PERFORMANCE OF CURED MATERIAL
(After 24 hr at 72
_
F on 3/8-16 steel Grade 8 Nuts and Grade 5 bolts)
Typical
Value Range
Breakaway Torque, Nm, 23 18 to 28
(in.lbs) (200) (160 to 250)
Prevail Torque, Nm 25 20 to 31
(in.lbs) (220) (180 to 270)
Where Breakaway Torque is the force required to initiate the fastener
movement and Prevail Torque is the force required to disassemble the
fastener once Breakaway Torque has occurred.
TYPICAL ENVIRONMENTAL RESISTANCE
Temperature Resistance
Product temperature range from -175°C to 232°C (-65°F to
450°F). The Breakaway and Prevailing Torque values
decrease as temperature increases, however the assembly
remains effective against vibration and leakage.
Chemical / Solvent Resistance
The product retains effective properties in contact with
automotive fluids, such as motor oil, gasoline, brake fluids,
transmission fluids, alcohol and antifreeze solutions.
GENERAL INFORMATION
This product is not recommended for use in pure oxygen
and/or oxygen rich systems and should not be selected as
a sealant for chlorine or other strong oxidizing materials.
For safe handling information on this product, consult the
Material Safety Data Sheet, (MSDS).
This product is not normally recommended for use on plastics
(particularly thermoplastic materials where stress cracking of
the plastic could result). It is recommended to confirm
compatibility of the product with such substrates.
ORDERING INFORMATION
Part Number Container Size
24026 6 ml tube, carded
27200 10 ml bottle, carded
OEM Interchange
Manufacture OEM Specifications Numbers
GM 12345493 998 5399
STORAGE
Products shall be ideally stored in a cool, dry location in
unopened containers at a temperature between 8
_
to 28
_
C
(46
_
to 82
_
F) unless otherwise labeled. Optimal storage is at
the lower half of this temperature range. To prevent
contamination of unused product, do not return any material to
its original container.
NOTE
The data contained herein are furnished for information only
and are believed to be reliable. We cannot assume
responsibility for the results obtained by others over whose
methods we have no control. Permatex, Inc. specifically
disclaims all warranties expressed or implied, including
warranties of merchantability or fitness for a particular
purpose, arising from sale or use of Permatex, Inc.
products and disclaims any liability for consequential or
incidental damages of any kind, including lost profits.
This product may be covered by one or more United States or
foreign patents or patent applications.
