Design Guide

Model & Series
Overall Dimensions
(W x D x H)
Shelving
(door models only) Capacity
Temperature
Range
Door Styles
Available
Outdoor
Model
15” Signature Series
HP15RS-3
14-7/8” x 24” x 34-1/4”
2 full-extension
pullout shelves
3.0 cu. ft. 33° - 42°F
1 2 3
HP15RO-3
4 5 6
24” Signature Series
HP24RS-3
23-7/8” x 24” x 34-1/4”
2 full-extension
pullout shelves
5.2 cu. ft. 33° - 42°F
1 2 3
HP24RO-3
4 5 6
Signature Series Sottile
HH24RS-3
23-7/8” x 18” x 32”
2 full-extension
pullout shelves
3.8 cu. ft. 33° - 42°F
1 2 3
HH24RO-3
4
24” C-Series
HC24RB-3
23-7/8” x 24” x 34-1/4”
2 full-extension
pullout shelves
5.2 cu. ft. 33° - 42°F
1 2 3
HC24RO-3
4 5 6
24” ADA-Compliant Series
HA24RB-3
23-7/8” x 24” x 32”
2 full-extension
pullout shelves
4.8 cu. ft. 33° - 42°F
1 2 3
4 5 6
15” Signature Series
HP15BS-3
14-7/8” x 24” x 34-1/4”
2 wine shelves +
1 full-extension
pullout shelf
3.0 cu. ft. 35° - 48°F
1 2 3
HP15BO-3
4
24” Signature Series
HP24BS-3
23-7/8” x 24” x 34-1/4”
2 wine shelves +
1 full-extension
pullout shelf
5.2 cu. ft. 35° - 48°F
1 2 3
HP24BO-3
4
Signature Series Sottile
HH24BS-3
23-7/8” x 18” x 32”
2 wine shelves +
1 full-extension
pullout shelf
3.8 cu. ft. 35° - 48°F
1 2 3
HH24BO-3
4
24” C-Series
HC24BB-3
23-7/8” x 24” x 34-1/4”
2 wine shelves +
1 full-extension
pullout shelf
5.2 cu. ft. 35° - 48°F
1 2 3
4
24” ADA-Compliant Series
HA24BB-3
23-7/8” x 24” x 32”
2 wine shelves +
1 full-extension
pullout shelf
4.8 cu. ft. 35° - 48°F
1 2 3
4
15” Signature Series
HP15WS-3
14-7/8” x 24” x 34-1/4” 5 wine shelves 3.0 cu. ft. 45° - 65°F
1 2 3
HP15WO-3
4
24” Signature Series
HP24WS-3
23-7/8” x 24” x 34-1/4” 5 wine shelves 5.2 cu. ft. 45° - 65°F
1 2 3
HP24WO-3
4
24” Signature Series
Dual-Zone
HP24DS-3
23-7/8” x 24” x 34-1/4”
2 wine shelves
(top zone) + 2-1/2
(bottom zone)
5.0 cu. ft.
(U) 51-65°F
(L) 45°-60°F
1 2 3
HP24DO-3
4
48” Signature Series
(single zone)
HP48WO-3-S
47-7/8” x 24” x 34-1/4”
4 wine shelves (left)
+ 6 (right)
12 cu. ft. 45° - 65°F
1 2 3
4
48” Signature Series
(two zone)
HP48WW-3-S
47-7/8” x 24” x 34-1/4”
4 wine shelves (left)
+ 6 (right)
11 cu. ft. 45° - 65°F
1 2 3
4
Signature Series Sottile
HH24WS-3
23-7/8” x 18” x 32” 4 wine shelves 3.8 cu. ft. 45° - 65°F
1 2 3
HH24WO-3
4
24” C-Series
HC24WB-3
23-7/8” x 24” x 34-1/4” 5 wine shelves 5.2 cu. ft. 45° - 65°F
1 2 3
4
24” ADA-Compliant Series
HA24WB-3
23-7/8” x 24” x 32” 4 wine shelves 4.8 cu. ft. 45° - 65°F
1 2 3
4
REFRIGERATORSBEVERAGE CENTERS
WINE RESERVES
QUICK REFERENCE
