15" Signature Series Operation / Installation Manual
50” area in which
electrical outlet must be located
17
9
/16” distance same
on both sides of cabinet
3
7
/64” minimum
clearance to side wall
15
25
/32” door
swing clearance
98° minimum door
swing for pull-out
shelf clearance
14
7
/8”
34”
25
5
/16”
22
1
/8” to front face
23
15
/16”
3
19
/32”
15
5
/64”
3.0 cubic feet interior capacity
Figure 1. Dimensions
