Installation & Operation Manual 15" Signature Series Refrigerator Refrigerated Drawers Beer Dispenser Beverage Center Wine Reserve
15" Signature Series Operation / Installation Manual TABLE OF CONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Warranty Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Installation Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Preparing the Space . . . . . . . . .
15" Signature Series Operation / Installation Manual GENERAL PRECAUTIONS DANGER Risk of child entrapment. Before you throw away your old refrigerator or freezer, take off the doors and leave shelves in place so children may not easily climb inside. DANGER Altering or cutting of the power cord, or removal of the power plug, or direct wiring can cause serious injury, fire and/or loss of property and/or life and will void the warranty. CAUTION • Do not lift unit by door handle.
15" Signature Series Operation / Installation Manual 50” area in which electrical outlet must be located 17 9/16” distance same on both sides of cabinet 3 7/64” minimum clearance to side wall 15 25/32” door swing clearance 98° minimum door swing for pull-out shelf clearance 25 5/16” 23 15/16” 22 1/8” to front face 14 7/8” 34” 3 19/32” 15 5/64” 3.0 cubic feet interior capacity Figure 1.
15" Signature Series Operation / Installation Manual PREPARING THE SPACE Make sure the installation opening is properly prepared. Refer to Figure 1 for space dimensions. CAUTION If unit is to be installed under a countertop, it is recommended that the countertop be supported by a structure other than the unit itself, to prevent damage to the countertop. IMPORTANT: For a cabinet door to operate properly, the door must open a minimum of 98° (see Figure 1).
15" Signature Series Operation / Installation Manual IMPORTANT: If installing on a concrete floor, concrete fasteners are required and are not included in the Anti-Tip kit. INSTALLATION CAUTION Finished flooring should be protected with appropriate material to avoid damage from moving the unit. “B” Measurement If unit has been laid on its back or sides, place unit upright and allow minimum of 24 hours before connecting power. 1.
15" Signature Series Operation / Installation Manual Wine Reserve The single door unit comes standard with six full extension black vinyl coated wine racks capable of storing 24 total wine bottles. Shelves are removable and adjustable to accommodate oversized (magnum) bottles. An additional fixed storage rack is nestled into the lower step for storage of an additional 5 wine bottles.
15" Signature Series Operation / Installation Manual Handle Installation Mounting bracket CAUTION Handle mounting on wood overlay door should be mounted on overlay panel only (not the door) to avoid damage to the factory door. 1. Handle must be attached to overlay before mounting overlay onto door. Mark rear of wood overlay panel with handle fastening locations. Nut Lock strike Lockwasher Lock body Screw 2.
Ø 1/8” /4” deep 3 11/16” 2 15/64” 1 25/32” 27 /32” 0” 5 25/32” 8 25/32” 14 9/16” 13 12/32” 13 3/16” 10 57/64” 15" Signature Series Operation / Installation Manual 1 Ø 3/4” thru 0” 27 /32” 2 15/64” 3 11/16” 13 /64” 10 7/64” 9” 3 /64” 1” 2 1/8” 3 1/4” 1 3/16” Ref Ø 1/8” 1 /2” Deep Typical 1 25/32” R 1 11/16” 49 27 /64” deep 1 1/16” 25 /64” 24 43/64” 19 /32” deep 27 /64” Detail C 13 39/64” 15 7/64” on locking doors only 16 39/64” C /64” deep 2” 1 1/8” These (2) holes not to be
15" Signature Series Operation / Installation Manual WOODEN WINE RACK TRIM FINISHING All wine racks come with an unfinished solid hardwood face, which can be removed and replaced with other wood to match the surrounding cabinetry. See Figure 10. The included unfinished faces can be finished and sealed. In many cases, stains and/or finishes have odors that may be objectionable in an enclosed area. To remove the front wood face from the wine shelf, simply pull out the wine shelf and remove the fasteners.
15" Signature Series Operation / Installation Manual Adjusting the Setpoint The setpoint is the desired temperature to be maintained in the unit. To adjust the setpoint: 1. Press the SET button located on the control panel (Figure 11). MAINTENANCE WARNING Shut off the electricity to the unit before cleaning the condenser and other routing maintenance. 2. Press the UP or DOWN arrow keys to the desired temperature. The controller will memorize the new setpoint.
15" Signature Series Operation / Installation Manual Primary Key Functions Turns on/off the power to the unit Disabled Manually defrosts the unit by holding button down Displays minimum stored temperature, also used for navigating control codes and changing displayed values within the various menu options Displays maximum stored temperature, also used for navigating control codes and changing displayed values within the various menu options.
15" Signature Series Operation / Installation Manual TROUBLESHOOTING If the unit appears to be malfunctioning, read through the OPERATION section first, then check the guide below to identify and resolve the problem. DANGER Electrocution hazard! Never attempt to repair or perform maintenance on the unit until the main electrical power has been disconnected. No interior light • Is the bulb loose? • Is the bulb burned out? Light stays on when the door is closed • Manual ON/OFF light switch is turn on.
15" Signature Series Operation / Installation Manual The refrigerated cabinet isn’t running • Is there electrical power to the unit? • Is the building circuit breaker or fuse on? • Is the ON/OFF keypad on? • Is the condenser area clean? The refrigerated compartment is warmer than usual • Is the control set properly? • Is the light staying on? • Is the condenser area clean and free of obstruction? • Has the door been open for a long time or more frequent door openings occurred? • Are the internal louvers and
" Signature Series Operation / Installation Manual PERLICK HOME REFRIGERATION PRODUCTS LIMITED WARRANTY ENTIRE PRODUCT- Full Two Year Warranty: For two years from the date of original installation, Perlick Corporation’s warranty covers all parts and labor to repair or replace any part of the product, which proves to be defective in material and workmanship.
15" Signature Series Operation / Installation Manual NOTES © 2008 15
15" Signature Series Operation / Installation Manual NOTES 16 © 2008
8300 W. Good Hope Road • Milwaukee, WI 53223 • 1-800-558-5592 • Fax: 414-353-7069 • www.bringperlickhome.com Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without warning. © 2008 15" One Door Cabinet Installation / Operation Manual Document No.
