OVERVIEW
LED worklight
Locking screw
Belt tension
lock knob
Head lock set screw
Pulley housing cover
Belt/pulley speed chart
Pulley housing knob
Motor pulley
Chuck
Belt
Belt tension
lock knob
Motor
Feed handle
Rack collar
Rack
Base
Support lock handle
Spindle pulley
Column
Table
Pointer
Depth tension knob
Bevel scale
Column lock handle
Depth scale
Safety key
ON/OFF switch
LED light switch
Table bevel lock Column support
Chuck key
Laser switch
Feed return spring
and cover
Quill
Table support
Laser
