- More Details about Capture Functions
155
Appendix
8
Exposure mode
Green program AE mode, e (Hyper program) mode,
b (Shutter-priority) mode, c (Aperture-priority) mode,
a (Hyper manual exposure) mode, and p (Bulb) mode
LCD Monitor
1.8 inch TFT Color LCD monitor with 118,000 pixels
(with backlight)
Shutter
Electronically controlled vertical-run focal-plane shutter,
Electromagnetic release, Speed range (1) Auto 1/4000-30
sec. (step less), (2) Manual 1/4000-30 sec. (1/2 EV step or
1/3 EV step) (3) Bulb
Shutter lock by setting Main switch in OFF position.
Lens Mount
Pentax KAF bayonet mount (K-mount with AF coupler, lens
information contacts)
Compatible Lens Pentax K
AF
2, K
AF
mount lenses, K
A
mount lenses
Autofocus System
TTL phase-matching autofocus system (SAFOX VIII), AF
operational brightness range: EV 0 to 19 (at ISO 200 with
f/1.4 lens), Focus lock available,
Focus Mode: AF.S (single) / AF.C (predictive continuous) /
MF (manual), focus points changeable.
Viewfinder
Penta-prism finder, Natural-Bright-Matte focusing screen,
Field of view: 95%, Magnification 0.95 × (with 50mm f/1.4
lens at ∞), Diopter: -2.5 to +1.5 m
-1
.
Viewfinder Indication
Focus Information: In-focus (Green lamp ] is lit), front or
back focus Indication signals and unable-to-focus indicator
(Green lamp ] blinks), Shutter speed indication, Aperture
indication, Flash ready indication b is lit,
Bar graph (exposure compensation, Over or Under
exposure indication in Metered Manual Mode, exposure
compensation indication), Av dial enabled, Tv dial enabled,
focus points, and @=(AE lock).
External LCD
b is lit=Built-in flash ready, Blinking=Flash recommended
warning or inappropriate lens warning, =Automatic
flash, =Red-eye reduction automatic flash,
=Wireless mode, =Wireless high-speed sync
mode, b=Flash ON, 9=Single-frame drive mode,
j=Consecutive shooting, g=Self-timer, h=Remote
control shooting, ?=Battery exhaustion warning,
V=Auto bracketing exposure (exposure setting steps can
be set to
1/2Ev or 1/3Ev), V=Multiple exposure, \=Busy display,
[=Beep, Shutter speed, Aperture value, Recorded Pixels,
Quality Level, Tv dial enabled, Av dial enabled, Sensitivity,
White Balance, Capacity remaining, Number of multiple
exposure shots, Bracket frames, and Exposure
compensation.
Preview Electronically controlled and usable in all exposure modes
