Installation
PC Connection From a Remote Network
You can connect the encoder to a PC or mobile device in the same remote network and control or manipulate it on the monitor of the
PC or mobile device
1.
Connect the network port in the rear panel to the router.
2.
Connect the [NETWORK] port of the router directly to the fixed IP LAN cable, or connect it to the ADSL modem.
POE
Local PC Local PC Local PC
Broadband
router
Internet Internet
4WANRESETPWR 3 2 1
POE
ADSL modem Local PC
Broadband
router
