INSTALLATION/OPERATION Integrated Positioning System Remote Monitor Kit IPS-RMK C2453M-D (2/06)
Contents Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Test the Handheld to Ensure It Is Ready for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Install the Monitor Batteries . . . . . . . . . . . . . . . . . . . . . . . . .
C2453M-D (2/06)
Welcome Thank you for purchasing Pelco's IPS-RMK, the remote monitor kit designed to assist in the installation and servicing of Spectra III ™ SE/Spectra III, Spectra ® Mini, Esprit®, or ExSite™ systems. Use the remote monitor kit to observe video, verify operation of the PTZ controls, check the address and baud settings, and program the positioning system. Software upgrades can also be performed with Spectra III SE/Spectra III, Spectra Mini, and ExSite systems.
Getting Started Before using the remote monitor kit, do the following: 1. Test the handheld to make sure it is ready for use. 2. Install the batteries for the monitor. TEST THE HANDHELD TO ENSURE IT IS READY FOR USE Batteries and software for the handheld were installed at the factory before the IPS-RMK was shipped. Before using the remote monitor kit check the battery gauge of the handheld to ensure that the batteries are still functioning.
INSTALL THE MONITOR BATTERIES The battery pack located on the back of the monitor holds 8 AA or 10 NiCad rechargeable batteries (batteries not included). To install the batteries, do the following: 1. Remove the mointor from the monitor compartment of the IPS-RMK (refer to Figure 1). 2. Press the tab located on the bottom of the battery pack of the monitor (refer to Figure 2). 3. Gently lift the battery back. 4. Install batteries. 5. Set the battery selection switch (refer to Figure 3). 6.
How to Assemble the Remote Monitor Kit Refer to Figure 4 for the following steps. Lift the handheld compartment. Open the bottom flap of the cable pouch. Pull the serial cable for the handheld out through the bottom of the pouch and connect to the bottom of the handheld. Secure excess cable and place back into pouch. Open the top flap of the cable pouch. Pull the BNC connector out through the top of the pouch. Connect to the VIDEO IN connector located on the top of the monitor.
Refer to Figure 5 for the following steps. Open the monitor compartment. Connect the top flap to the side flap. This will reduce the glare of the sun on the monitor when using the kit outdoors. This step is not required if there is no glare on the monitor. Fold the loose part of the bottom flap under and attach to the Velcro®. Open the handheld compartment. Attach the two side Velcro strips to the Velcro strips on the monitor compartment. This will support the handheld during use.
Figure 6. Remote Monitor Kit Connected to a IPS-RDPE-2 Figure 7. Remote Monitor Kit Connected to a Spectra III Dome 10 Figure 8.
How to Adjust the Monitor Figure 9. Monitor Controls NTSC/PAL switch: Set the NTSC/PAL switch to the correct setting for your location. Manual/Auto switch: Select Auto to use the preset standard color adjustment. Set to Manual to set the color, tint, and brightness manually. Color, tint, and brightness controls cannot be adjusted manually if the switch is set to Auto. ON/OFF switch: Do not leave the monitor ON when it is not being used. Battery life is 2.5 to 3 hours.
How to Control the Positioning System Using the Handheld The Spectra III, Spectra Mini, Esprit, and ExSite utilities are installed on the handheld contained in this kit. The handheld is ready for immediate use. Before using the handheld to control a system, know how to operate the handheld. For instructions on how to operate the handheld, refer to the manual shipped in the handheld box. 1. Turn the handheld ON. 2. Tap the application icon. APPLICATION ICON Figure 10. Handheld Main Menu 3.
PTZ CONTROL MENU OPEN (Iris Open): Tap the OPEN button to make a selection. CLOSE (Iris Close): Tap the CLOSE button to cancel a selection. NEAR (Focus Near): Tap the NEAR button to focus near. FAR (Focus Far): Tap the FAR button to focus far. IN (Zoom In): Tap the IN button to zoom near. OUT (Zoom Out): Tap the OUT button to zoom far. PGM (Preset 95) - Tap the PGM button to access the programming menu for the dome system.
How to Upload Software Operating software and language files can be uploaded to a Spectra III Series, Spectra Mini, or ExSite system. The latest version of the control/upload utility is installed on the handheld. To upload future revisions, refer to How to Download Software to the Handheld . To upload software using the IPS-RDPE-2 remote data port the following software must be installed: • Spectra III dome drive must have operating software version 1.2 or higher installed.
3. Enter the name of the software title where the blinking cursor appears on the screen. SOFTWARE FILE NAME INDICATES UPLOAD IS COMPLETE UPLOAD BUTTON Figure 14. Enter Software Title 4. Tap the Upload button. The software upload starts. 5. Wait until "Done" appears on the screen before unplugging the RJ-45 cable. WARNING: Do not cycle power to the system during the upload process. The "Done" message on the handheld indicates only that the first part of the upload is done.
Troubleshooting Error Message Please Choose a File To Upload Explanation No file was specified before clicking Upload. File Not Found The file specified is not on the handheld device. Go to the handheld information screen to verify the file exists. Use the HotSync function to install the software file to the handheld and try again. Error Opening Port The program cannot open the COM 1 port. Another application may be using the port. Close the other application, or perform a soft reset to reset the port.
Specifications IPS-RMK Handheld Size Weight Memory Battery Display Expansion Operating System HotSync® Software Monitor Display Backlight Input Signal Dot Format Dot Pitch Brightness Rating Number of Pixels Contrast Ratio Viewing Angle L/R/T/B Pixel Configuration Power Requirements Power Consumption Battery Pack Battery Life Input Signal Level Operating Temperature Storage Temperature Connectors Video In/Out DC Input Power Unit Weight Shipping Weight IPS-CABLE Connectors Receiver Video Control Length 4.
PRODUCT WARRANTY AND RETURN INFORMATION WARRANTY Pelco will repair or replace, without charge, any merchandise proved defective in material or workmanship for a period of one year after the date of shipment. Exceptions to this warranty are as noted below: • Five years on FT/FR8000 Series fiber optic products. • Three years on Genex® Series products (multiplexers, server, and keyboard).
REVISION HISTORY Manual # C2453M C2453M-A C2453M-B C2453M-C C2453M-D Date 7/02 4/03 1/04 7/05 2/06 Comments Original version. Added Esprit and IPS-RDPE-2 information. Revised per ECO# 03-9497 for software revision. Added ExSite system information. Added Spectra Mini system information. Pelco, the Pelco logo, Spectra, Genex, Coaxitron, Esprit, Camclosure, and Legacy are registered trademarks of Pelco. Velcro is a registered trademark of Velcro Industries.
