Connecting to an HDTV with an HDMI Connector
Cable Used in this Conguration
• 1HDMICable
Notes:
• TheHDMIportontheTVmustsupporthigh-bandwidthdigitalcontentprotection(HDCP).
• TheHDMIinterfacesupportsDolby
™
Digital 5.1 audio.
WARNING:
Electric shock hazard! Unplug all electronic devices before connecting or
disconnecting any device cables to the receiver.
T16503
