Because the connections

for a high-denition (HD)

or standard-denition (SD)

TV are dierent, you must

determine if your TV is HD

or SD. Your TV must

receive HD signals for

you to enjoy the benets of HDTV. Refer to the manual that came with your

TV for more information.

See page 26 for more information on picture formats.

Make one of the following connections for your home network:

• Ifyourhomenetworkusescoaxialcable,usetheTOWALLconnector

on the receiver. See page 11.

• Ifyourhomenetworkusestwistedpaircable(phonelinewiring),use

theTOWALLconnectoronthereceiverandanadapterthatconverts

twisted pair to coaxial. See page 11.

• Ifyourhome network uses Ethernet (CAT-5) cable, use the NETWORK

connector on the receiver. See page 11.

Connecting the Receiver

To connect your receiver to your network and home entertainment devices, complete

these steps.

Identify the additional

consumer electronic devices

you will connect to the

receiver and TV. See pages

15 through 23 and refer to

the owner’s manual for the

device.

Plug the receiver and the TV into an AC power source that is not

controlled by a switch.

Make the connections for your TV, VCR, and DVD recorder as follows:

• IfyouareusinganHDTV,see page 12 and the connection diagrams in

this manual.

• Ifyouareusingastandard-denitionTV,see page 13 and the

connection diagrams in this manual.

• IfyouwanttorecordsomeprogramsonVCRtapeorDVD,see page

14 and the connection diagrams in this manual.



Home Theater

Other

DVD

VCR
