Installation Manual

ISSUED: 03-11-11 SHEET #: 125-9196-1
2 of 3
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112.
2
DRYWALL
• Drywallmustbe1/2"orthicker.
• Makesurethatthewallwillsafelysupportthecombinedloadoftheequipmentandallattachedhardwareand
components.
• Usingapowerdrilltosecureanchorsmaycauseanchorstofail.
WARNING
Installation to Drywall
NOTE:Flangeonwallshelffacesupward.
Usingwallshelf(A)asatemplate,markthecenterofthetwomountingholes.Usingaphillipsscrewdriver,install
twoanchors(C) into drywall as shown below.
Looselyfastenwallshelf(A)todrywallusingtwo#8x1”phillipsheadscrews(D).
Level,hold,andthentightenallscrews.
1
A
B
C
NOTE:MAKESURE
THATANCHORS(C)
ARE LEVEL
TOP
NOTE: FLANGE FACES UPWARD
5.5"
(140mm)
