User Manual

6. Read the current in display.

Note:

1. If the current range is not known beforehand, set the

FUNCTION switch to the highest range and work down.

2. When only the figure "OL" is displayed overrange is being

indicated and the FUNCTION switch must be set at higher

range.

3. Caution: The maximum input current is 200 mA.

5.5. AC Current Measurements

1. Set the function switch to the µA/mA position.

2. Press the MODE-button to indicate “AC” on the display.

3. Remove power from the circuit under test, then open up the

circuit at the point where you wish to measure current.

4. Connect the test leads in series with the load under

measurement.

5. Apply power to the circuit.

6. Read the current in display.

5.6. Resistance Measurement

WARNING! To avoid electric shock, disconnect power to the

unit under test and discharge all capacitors before taking

any resistance measurements. Remove the batteries and

unplug the line cords.

1. Set the function switch to the Ω /

))) position.

-36-
