A-12 Frequency Weighting Curves HVM200 Manual
31.5 31.62 -6.16 -11.87 -24.01 +1 / -1
40.0 39.81 -8.11 -13.97 -26.08 +1 / -1
50.0 50.12 -10.09 -16.15 -28.24 +1 / -1
63.0 63.10 -12.43 -18.55 -30.62 +1 / -1
80.0 79.43 -15.34 -21.37 -33.43 +1 / -1
100 100.0 -18.72 -24.94 -36.99 +1 / -1
125 125.9 -23.00 -29.39 -41.43 +2 / -2
160 158.5 -28.56 -34.57 -46.62 +2 / -2
200 199.5 -34.03 -40.20 -52.24 +2 /
-
250 251.2 -39.69 -46.04 -58.09 +2 / -
315 316.2 -45.65 -51.98 -64.02 +2 / -
400 398.1 -51.84 -57.95 -70.00 +2 / -
Freq ( Hz)
Nominal
Freq ( Hz)
True
Wm dB Wc dB Wd dB
Tolerance
dB
