HVM200 Manual Typical Measurement Ranges A-5
Reference Calibration Vibration
The reference calibration vibration is 1 m/s
2
Typical Measurement Ranges
Need specs for all filters. In both mv/g and dB?
Frequency Weighting Curves
Fa (Flat 0.4 Hz to 100 Hz)
Freq ( Hz)
Nominal
Freq ( Hz)
True
Fa dB Tolerance
dB
0.100 0.1000 -24.10 +2/-
0.125 0.1259 -20.12 +2/ -
0.160 0.1585 -16.19 +2/ -
0.200 0.1995 -12.34 +2/-
0.250 0.2512 -8.71 +2/-2
0.315 0.3162 -5.51 +2/-2
0.400 0.3981 -3.05 +1/-1
0.500 0.5012 -1.48 +1/-1
0.630 0.6310 -0.65 +1/-1
0.800 0.7943 -0.27 +1/-1
1.00 1.000 -0.11 +1/-1
1.25 1.259 -0.04 +1/-1
1.60 1.585 -0.02 +1/-1
2.00 1.995 -0.01 +1/-1
2.50 2.512 0.00 +1/-1
3.15 3.162 0.00 +1/-1
4.00 3.981 0.00 +1/-1
