HVM200 Manual Data Communication CharacteristicsA-3
• 2 GB file size limit. No limit to number of files or setups.
• No limit to number of files or setups
• 5 minute (typical) data retention for clock during battery change
• Data and settings are stored in non-volatile memory
Data Rate
• USB 2.0 hi-speed
• Data rate > 1 MBps
• Wi-Fi 802.11 b/g
Connections
• Input: 1/4-28 4-pin male
• Charging and communicaiton: Micro USB
Data Communication Characteristics
Need specs.
SSID Connection:
Bandwidth Consumption:
USB effects:
FCC Wi-Fi Characteristics:
Maximum Data Rate:
Electrical Characteristics
Power Consumption
Need specs
Power Supply
• User replaceable 2100 mAh rechargeable Lithium-ion battery
• Operation time > 12 hours
• Battery life is maintained at 80% after 2 weeks without operation
• External Power: Micro USB cable or Larson Davis Power Supply PSA035
