Specifications

5
Introducing the Motherboard
Table of Motherboard Components
15 AUDIO1 Front panel audio header
2 CPU Socket
6 IDE1 Primary IDE connector
8 SATA1~2 Serial ATA connectors
10 CLR_CMOS Clear CMOS jumper
5 FDD Floppy disk drive connector
12 PCI1~2 32-bit add-on card slots
1 CPU_FAN CPU cooling fan connector
20 ATX12V 4-pin +12V power connector
3 DIMM1~2 240-pin DDR2 SDRAM slots
16 CD_IN Analog audio input connector
4 ATX_POWER Standard 24-pin ATX power connector
11 USB3~4 Front Panel USB headers
19 SYS_FAN1 System cooling fan connector
18 PCIEX1 PCI Express x1 Slot
9 PANEL1 Front Panel switch/LED header
14 SPDIFO1* SPDIF out header
17 PCIEX16 PCI Express slot for graphics interface
13 CNR1* Communications Networking Riser slot
Socket AM2 for AMD Sempron/Athlon 64/
Athlon 64 X2 Dual-Core/Athlon 64 FX pro-
cessors
LABEL COMPONENT
7 IDE2 Secondary IDE connector
This concludes Chapter 1. The next chapter explains how to install the motherboard.
“*” stands for optional components.
