Unit installation / test
Following the completed installation of this equipment, no further maintenance or testing is required.
It is advisable to ensure that any third party backup power supplies or recovery procedures are checked regularly
to ensure that the operation of the Paxton system is not compromised.
Maintenance
Part Description
345-220-US PROXIMITY P50M HID
TM
reader
Fitting Kit (5) Cable clips
(3) No. 6 x
3
/4 woodscrew - zinc
(3) Wall plugs 22mm
(1) 8mm x 3mm pan head self tapping screw - zinc
(2) Backbox screws
Parts List
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
When choosing a location for the reader, ensure that it is at least 12 inches from other readers. This will include
readers mounted on the other side of the same wall as the radio signal will cause interference and reduce the read
range. Mounting the reader on metal surfaces will reduce the read range.
Standard Unit - Drill a hole in the surface for the rear data cable. Secure the unit to the surface with three screws
as per tting diagram on page 1. Suitable screws and xings are provided for installing the unit to a wall. Ensure
the data cable has free access at the rear.
A choice of black and white covers are also provided. Hook the required cover over the top of the reader, press
home at the bottom and secure with the single xing screw.
The reader will beep and all the LED's should display after powering on the control unit. Presenting a user card to
the reader will cause the LED's to briey change to a single Green or Red LED.
Check the following FAQs section for assistance if any problems are encountered.
