Installation Instructions

Page 3 of 3
210826
ASSEMBLY INSTRUCTIONS (continued)
The following parts are available for reorder if damaged or missing. Call our toll free at 1-800-887-6326.
Spare Parts List:
Assembly Kit
6246MM (1 SET)
Wood Shade
5134WL
Socket Fixer
6247MM
B
FF
EE
Socket Ring
Shade Holder
5
● To clean, turn off and wipe with a damp, non-abrasive cloth.
1) The light does not work:
a) Make sure the wall switch and circuit breaker are on.
b) Make sure the wiring is correct.
2) Fuse blows or circuit trips when light is turned on.
Check for crossed wires, ensure wiring is correct.
If unable to fix any of the above issues, please consult a certified electrician.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
CARE AND MAINTENANCE
TROUBLESHOOTING
FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails
due to a defect in material workmanship within five (5) years from the date of original purchase, simply bring this
lighting fixture with the original sales receipt back to your nearest MENARDS retail store. At its discretion, PATRIOT
LIGHTING agrees to have the product or any defective part(s) repaired or replaced with the same or similar PATRIOT
LIGHTING product or part free of charge, within the stated warranty period, when returned by the original purchaser
with original sales receipt. This warranty; (1) excludes expendable parts including but not limited to light bulbs; (2) does
not cover damage that has resulted from abuse or misuse; and (3) does not cover any losses, labor, injuries to
persons/property or costs. This warranty does give you specific legal rights and you may have other rights, which vary
from state to state.
R
R
R
R
B
Mounting Screw
X2
Wire Connector
X3
AA BB
Bolt Nut
X2
DDCC
Mounting Plate Unit
X1
FF
EE
6W LED Bulb
Type A (included)
8110LED
Turn on the power at fuse or circuit box.
5. Secure the wood shades (B) onto the shade holders and tighten the wood shades (B)
using the socket rings and socket fixer (EE). Install 3 LED medium base bulbs (FF)
(included).
For fear of damage from high temperatures, use LED bulbs only.
See relamping label at socket area or packaging for maximum wattage allowed.
Note: There are 3 extra wood slats included in the package as replacements.
If the wood slats loosen from the shade, fasten or replace them yourself.
