User's Manual

®
Model No.UI-5110 Introduction
2
About the Shrouded Voltage Probe
The PASCO UI-5110 Shrouded Voltage Probe connects to an eight pin DIN jack such as the ANALOG INPUT
ports on the 850 Universal Interface. The probe has a built in automiatic identification (“auto ID”) chip. When
connected to the 850 Universal Interface, the PASCO Capstone software automatically determines that the probe
has been plugged in.
Note that the small indent on one side of the metal part of the DIN plug should face
up when the probe is plugged into the interface. The Shrouded Voltage Probe mea-
sures direct current (DC) or alternating current (AC).
The UI-5218 Extension Cable is 1.8 meters long with an eight pin male DIN plug at
one end and an eight pin female DIN plug at the other end. Use one to extend the distance that the Shrouded Volt-
age Probe can reach.
Probe Setup
1. Connect the Shrouded Voltage Probe to a compatible PASCO interface.
2. If you will be using a computer, connect the interface to the computer’s USB
port.
Technical Support
For assistance with any PASCO product, contact PASCO at:
For information about the Voltage Probe, Shrouded and the
latest version of this Instruction Sheet, visit the PASCO web
site at www.pasco.com and enter UI-5110 in the Search window.
Product End of Life Disposal Instructions:
This electronic product is subject to disposal and recycling regulations that vary by country and region. It is your
responsibility to recycle your electronic equipment per your local environmental laws and regulations to ensure that it
will be recycled in a manner that protects human health and the environment. To find out where you can drop off your
waste equipment for recycling, please contact your local waste recycle/disposal service, or the place where you pur-
chased the product.
The European Union WEEE (Waste Electronic and Electrical Equipment) symbol (to the right)
and on the product or its packaging indicates that this product must not be disposed of in a stan-
dard waste container.
Address: PASCO scientific
10101 Foothills Blvd.
Roseville, CA 95747-7100
Phone: [phone] (worldwide)
800-772-8700 (U.S.)
Web: www.pasco.com
Email: [e-mail]
Indent
DIN plug
WARNING: The Shrouded Voltage Probe is not designed to measure line volt-
age. Do not connect any PASCO probe or sensor into a wall socket. Line volt-
age such as 100 to 240 volts will damage the probe and the interface.
For information on set-
ting up the data acquisi-
tion software and
recording data, refer to
the User’s Guide for the
interface and software.
