Table 5-1 Part Numbers
Description Park Air Part Number Notes
Modules:
PSU B68-70000701
Processor module B68-70000711
RF control module B68-70000712
Control head B68-70000714
Interface module B68-70000715
RF PA B68-70000716 Transceiver only
RF switch B68-70000735 Receiver only
Guard receiver module B68-70000725 Optional module
Custom interface module Allocated for an individual user. Optional module
Parts:
Coaxial cables
See separate list –
Table 5-6 on
page 5-38
Cable Lemo to USB 17N12000021 For use with DLA
Heatsink fan 1 and 2 69S12833142H
See
Fig 5-7 on
page 5-13
Main chassis fan 69S12833142M
See
Fig 5-7 on
page 5-13
Thermal pad for PSU 46-00000615
Thermal pad for RF PA 46-00000591
Fuse (F1) dc input, F30A 32V 29-01460202
Fuse (F2) ac input, T10AH
250 V
29-01100102
