User's Manual
Table Of Contents
- Contents
- About This Guide
- About the FrameSaver DSL Unit
- User Interface and Basic Operation
- Configuration Procedures
- Configuration Options
- Overview
- Using the Easy Install Feature
- Setting Up So the Router Can Receive RIP
- Entering System Information and Setting the System Clock
- Configuration Option Tables
- Configuring the Overall System
- Configuring the Physical Interfaces
- Configuring Frame Relay for the Data Port
- Configuring ATM for the Network Interface
- Configuring Circuit and DLCI Records
- Configuring PVC Connections
- Setting Up Management and Communication Options
- Configuring Node IP Information
- Configuring Management PVCs
- Configuring General SNMP Management
- Configuring Telnet and/or FTP Session Support
- Configuring SNMP NMS Security
- Configuring SNMP Traps
- Configuring the Ethernet Port
- Configuring the Communication Port
- Configuring the COM Port to Support an External Modem
- Security and Logins
- Operation and Maintenance
- FTP Operation
- Troubleshooting
- Setting Up OpenLane for FrameSaver Devices
- Setting Up Network Health for FrameSaver Devices
- Menu Hierarchy
- SNMP MIBs and Traps, and RMON Alarm Defaults
- Connectors, Cables, and Pin Assignments
- Technical Specifications
- Equipment List
- Index
vii
9783-A2-GB20-00
July 2000
About This Guide
Purpose and Intended Audience
This document contains information that applies to the FrameSaver DSL 9783. It
is intended for system designers, engineers, administrators, and operators who
are familiar with the functional operation of digital data communications
equipment and frame relay networks.
Document Organization
Section Description
Chapter 1
About the FrameSaver DSL Unit.
Identifies how the
FrameSaver DSL 9783 fits into Paradyne’s Service Level
Management (SLM) solution, and describes the unit’s
basic features and, if ordered, its advanced Service Level
Verification and Management (SLV and SLM) features.
Chapter 2
User Interface and Basic Operation.
Shows how to
navigate the user interface.
Chapter 3
Configuration Procedures.
Shows how to access and save
configuration options.
Chapter 4
Configuration Options.
Describes the configuration options
available on the FrameSaver DSL 9783.
Chapter 5
Security and Logins.
Provides procedures for controlling
access to the unit and setting up logins.
Chapter 6
Operation and Maintenance.
Provides procedures to
display unit identification information and perform file
transfers, as well as how to display and interpret status
and statistical information.
Chapter 7
FTP Operation.
Shows how to use File Transfer Protocol to
upgrade system software and transfer collected data.
