Configuring ATM for the Network Interface
Select ATM from the Network menu to display or change the ATM options (see
Table 4-8).
Main Menu
→
Configuration
→
Network
→
ATM
Table 4-8. Network ATM Options
Cell Delineation Error Event Threshold
Possible Settings: 1–1000
Default Setting: 10
Specifies the number of Out of Cell Delineation (OCD) events that must occur in a one
minute interval for a Loss of Cell Delineation (LCD) alarm to be declared.
1 – 1000 – S
pecifies the LCD threshold.
