Configuration Options
4-5
9783-A2-GB20-00
July 2000
Table 4-1. Easy Install Configuration Options (2 of 2)
TS Access (VCI)
Possible Settings: 32–255
Default Setting: 0
Specifies the VCI on the network interface to be used for troubleshooting by the service
provider. VPI 0, VCI 35 is the default management path between the FrameSaver DSL
unit and the Hotwire GranDSLAM.
32 – 255 – Specifies the VCI.
Create a Dedicated Network Management Link
With the cursor on the Create a Dedicated Network Management Link field, press Enter.
When prompted, enter a DLCI for the link from 16 to 1007. The management link DLCI
is added or modified.
Ethernet Port Options Screen
With the cursor on the Ethernet Port Options Screen field, press Enter. The Ethernet
Port Options screen appears. See
Configuring the Ethernet Port
on page 4-40.
After configuring the Ethernet port configuration options, save your changes. Then
press the Esc key to return to the Easy Install screen.
Network 1 DSL Line Rate (Kbps)
Possible Settings: AutoRate, 144, 192, 272, 384, 400, 528, 768, 1168, 1552, 2320
Default Setting: AutoRate
Determines whether the rate on the DSL interface is automatically detected using the
Conexant AutoBaud algorithm, or set to a specific value.
144 – 2320 – The DSL line rate is set to the specified value.
AutoRate – The DSL line rate is automatically detected from the DSL interface.
