Configuration Options
4-3
9783-A2-GB20-00
July 2000
Using the Easy Install Feature
An Easy Install screen is provided for custom configurations, but is not required
for normal installation.
The Easy Install feature allows minimal configuration of the FrameSaver DSL
Unit. Once the unit is installed and minimal configuration is completed using Easy
Install, the NOC (Network Operation Center) can complete configuration of the
unit and verify the setup.
Main Menu
→
Easy Install
Easy Install Screen Example
main/easy_install 9783
Device Name: Node A 05/13/2000 04:01
EASY INSTALL
Node IP Address: 000.000.000.000
Clear
Node Subnet Mask: 000.000.000.000
Clear
TS Access: VPI,VCI
0 , 35
Create a Dedicated Network Management Link
Ethernet Port Options Screen
Network 1 DSL Line Rate (Kbps) AutoRate
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu M
ainMenu Exit
S
ave
Table 4-1, Easy Install Configuration Options, describes the entries on the Easy
Install screen.
