Configuration Procedures
3-3
9783-A2-GB20-00
July 2000
Configuration Option Areas
The FrameSaver unit arrives with configured factory default settings, which are
located in the Factory Default Configuration option area. You can find the default
settings for configuration options in the:
H
FrameSaver DSL 9783 Quick Reference
H
Configuration Option Tables
in Chapter 4,
Configuration Options
If the factory default settings do not support your network’s configuration, you can
customize the configuration options to better suit your application.
Four configuration option storage areas are available.
Configuration Option Area
Description
Current Configuration The currently active set of configuration options.
Customer Configuration 1 An alternate set of configuration options that the
customer can set up and store for future use.
Customer Configuration 2 Another alternate set of configuration options that the
customer can set up and store for future use.
Default Factory Configuration A read-only configuration area containing the factory
default set of configuration options.
You can load and edit default factory configuration
settings, but you can only save those changes to the
Current, Customer 1, or Customer 2 configuration
option areas.
The Current, Customer 1, and Customer 2 configuration
option areas are identical to the Default Factory
Configuration until modified by the customer.
