User Interface and Basic Operation
2-3
9783-A2-GB20-00
July 2000
If your login was . . . Then the . . .
Valid Main Menu appears. Begin your session.
NOTE: If your login is valid, but access is denied, there
are two currently active sessions.
Invalid Message, Invalid Password, appears on line 24, and
the Login screen is redisplayed.
After three unsuccessful attempts:
H A Telnet session is closed.
H The User Interface Idle screen appears for a directly
connected terminal or modem.
H An SNMP trap is generated.
H Access is denied.
See your system administrator to verify your login (Login
ID/Password combination).
FrameSaver units support two sessions simultaneously. If two sessions are
currently active, wait and try again.
H If two sessions are currently active and you are attempting to access the
unit through Telnet, the local Telnet client process returns a Connection
refused: message at the bottom of the screen.
H If two sessions are currently active and you are attempting to access the unit
over the COM port (using a terminal or external modem, not via Telnet), the
User Interface Already In Use screen is redisplayed. In addition, the type of
connection (Telnet Connection or Direct COM Port Connection) for each
current user is identified, along with the user’s login ID.
" Procedure
To end the session:
1. Press Ctrl-a to switch to the function keys area of the screen.
2. Type e (E
xit) and press Enter.
— For a terminal-connected to the COM port, the session is ended.
— For a modem connected to the COM port, the session is ended and the
modem is disconnected.
— For a Telnet connection, the session is closed and, if no other Telnet or
FTP session is occurring over the connection, the modem is
disconnected.
If ending a session from the Configuration branch, see
Saving Configuration
Options
in Chapter 3,
Configuration Procedures
.
