2-1
9783-A2-GB20-00
July 2000
User Interface and
Basic Operation
2
This chapter explains how to access, use, and navigate the menu-driven user
interface. It includes the following:
H
Logging On
H
Main Menu
H
Screen Work Areas
H
Navigating the Screens
—
Keyboard Keys
—
Function Keys
—
Selecting from a Menu
—
Switching Between Screen Areas
—
Selecting a Field
—
Entering Information
What appears on the screens depends on:
H Current configuration – How your network is currently configured.
H Security access level – The security level set by the system administrator
for each user.
H Data selection criteria – What you entered in previous screens.
