Equipment List
E-2
9783-A2-GB20-00July 2000
Description
Model/Feature
Number
NMS Products
OpenLane Enterprise 7805-D1-001
OpenLane Workgroup 7805-D1-003
NetScout Manager Plus – For UNIX or Windows NT 9180
NetScout Server – For UNIX or Windows NT 9190
NetScout WebCast – For UNIX or Windows NT 9155
Optional Features
Wall Mounting Kit for 1-Slot Housing 9001-F1-891
Shelf Mounting Kit for 1-Slot Housings 9001-F1-894
Cables
This table lists cables you can order.
Description Part Number Feature Number
RJ48C DSL Network Cable,
RJ48C-to-RJ48C/RJ49C
(20 feet – 6.1 meters) –
For use in the U.S.
035-0209-2031 3100-F1-500
Standard EIA-232 Straight-Through Cable,
DB25-to-RJ48 (14 feet – 4.3 meters) –
For connection to an asynchronous
terminal or PC with an 8-pin modular
interface.
035-0314-1431 3100-F2-540
Standard EIA-232 Straight-Through Cable,
DB25-to-D-Sub9 (14 feet – 4.3 meters) –
For connection to a PC with a D-Sub9
interface.
035-0313-1431 3100-F2-550
V.35 DTE Adapter, EIA-530A-to-V.35 –
For connection to equipment with V.35
,
MS34 connectors.
035-0244-0031 3100-F1-570
Standard EIA-232-D Crossover Cable
(14 feet – 4.3 meters) –
For connection to an external device.
035-0336-1431 9008-F1-550
