D-1
9783-A2-GB20-00
July 2000
Technical Specifications
D
Table D-1. FrameSaver DSL Technical Specifications (1 of 2)
Specification
Criteria
Approvals
FCC Part 15
Safety
Class A digital device
Refer to the equipment’s label for safety information.
Physical Environment
Operating temperature
Storage temperature
Relative humidity
Shock and vibration
32°F to 122°F (0°C to 50°C)
–4°F to 158°F (–20°C to 70°C)
5% to 85% (noncondensing)
Withstands normal shipping and handling
Power Consumption and
Dissipation
4.5 watts, 60 Hz 3, 0.135 A at 120 Vac12
Result: 15.4 Btu per hour
Physical Dimensions
Height (with feet)
Height (without feet)
Width
Depth
2.1 inches (5.3 cm)
2.0 inches (5.1 cm)
6.2 inches (15.7 cm)
8.7 inches (22.1 cm)
Weight 1.38 lbs (0.62 kg)
