SNMP MIBs and Traps, and RMON Alarm Defaults
B-30
9783-A2-GB20-00July 2000
Table B-15. Alarm OID Cross-Reference (2 of 2)
Object ID (OID) MIB/TagItem
.1.3.6.1.4.1.1795.2.24.2.6.9.4. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.3.1.7.I.D Current Latency
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyLatest
.1.3.6.1.4.1.1795.2.24.2.6.9.4.4.2.1.2.I.N Frame Size Upper Limits
(1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtFrameSzUpLimit
.1.3.6.1.4.1.1795.2.24.2.6.9.4.4.2.1.3.I.N Frame Size Count (1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtFrameSzCount
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.6.I Rx Short Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxShort
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.7.I Rx Long Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxLong
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.11.I LMI Sequence Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkSeqErr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.14.I Tx Discards
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTxDiscards
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.15.I Rx Discards
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxDiscards
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.16.I Rx Nonoctet Aligns
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxNonOctet
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.17.I Rx CRC Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxCrcErrs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.18.I Rx Illegal Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxIlFrames
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.19.I Tx Total Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotTxErrs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.20.I Rx Total Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotRxErrs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.28.I Rx Overruns
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxOverruns
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.29.I Tx Underruns
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTxUnderruns
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.32.I Total LMI Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotalLMIErrs
