SNMP MIBs and Traps, and RMON Alarm Defaults
B-29
9783-A2-GB20-00
July 2000
Table B-15. Alarm OID Cross-Reference (1 of 2)
Object ID (OID)
Item MIB/Tag
.1.3.6.1.2.1.10.32.2.1. . .
.1.3.6.1.2.1.10.32.2.1.4.I.D Rx FECNs
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedFECNs
.1.3.6.1.2.1.10.32.2.1.5.I.D Rx BECNs
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedBECNs
.1.3.6.1.2.1.10.32.2.1.6.I.D Frames Sent
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitSentFrames
.1.3.6.1.2.1.10.32.2.1.7.I.D Tx CIR Utilization
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitSentOctets
.1.3.6.1.2.1.10.32.2.1.7.I.D Tx DLCI Link Utilization
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitSentOctets
.1.3.6.1.2.1.10.32.2.1.8.I.D Frames Received
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedFrames
.1.3.6.1.2.1.10.32.2.1.9.I.D Rx DLCI Link Utilization
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedOctets
.1.3.6.1.4.1.1795.2.24.2.6.9.4. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.17.I.D Tx Frames Exceeding CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciTxFrOutCIR
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.20.I.D Frames Dropped by Network
MIB:
pdn_FrExt.mib (E)
Tag:
frFrExtDlciNetDropFr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.23.I.D Missing Latency Responses
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciMissedSLVs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.2.1.6.I.D Congested Seconds
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciStsCongestedSecs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.2.1.2.I.D Inactive Seconds
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciStsInactiveSecs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.3.1.5.I.D Average Latency
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyAvg
