SNMP MIBs and Traps, and RMON Alarm Defaults
B-28
9783-A2-GB20-00July 2000
Table B-14. History OID Cross-Reference (5 of 5)
Object ID (OID)
1
MIB/TagItem
.1.3.6.1.4.1.1795.2.24.2.6.9.4.10.3.1. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.10.3.1.2.I.N Port Burst Upper Limits 1–4
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkUtilUpLimit
.1.3.6.1.4.1.1795.2.24.2.6.9.4.10.3.1.3.I.N Rx Port Burst Octets 1–5
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkUtilRxOctets
.1.3.6.1.4.1.1795.2.24.2.6.9.4.10.3.1.4.I.N Tx Port Burst Octets 1–5
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkUtilTxOctets
1
I = Interface ID of the frame relay link
D = DLCI number
N = Additional numeric index used by tables, like frame or burst size
H = Host control index
P = Protocol index
T = The time mask
See Table B-15 for an RMON alarm OID cross-reference.
