SNMP MIBs and Traps, and RMON Alarm Defaults
B-27
9783-A2-GB20-00
July 2000
Table B-14. History OID Cross-Reference (4 of 5)
Object ID (OID)
1
MIB/TagItem
.1.3.6.1.4.1.1795.2.24.2.6.9.4.5.2.1. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.5.2.1.2.I.D.N Burst Upper Limit (1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtBurstUpLimit
.1.3.6.1.4.1.1795.2.24.2.6.9.4.5.2.1.3.I.D.N Burst Octets (1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtBurstOctets
.1.3.6.1.4.1.1795.2.24.2.6.9.4.5.2.1.4.I.D.N Burst Frames (1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtBurstFrames
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.2.I LMI Unavailable Seconds
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkNoLMISecs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.6.I Rx Short Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxShort
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.7.I Rx Long Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxLong
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.11.I LMI Sequence Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkSeqErr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.15.I Rx Discards
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxDiscards
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.17.I Total Rx CRC Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxCrcErr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.18.I Rx Illegal Frames
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxIlFrames
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.19.I Total Tx Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotTxErrs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.20.I Total Rx Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotRxErrs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.32.I Total LMI Errors
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkTotLMIErrs
1
I = Interface ID of the frame relay link
D = DLCI number
N = Additional numeric index used by tables, like frame or burst size
H = Host control index
P = Protocol index
T = The time mask
