SNMP MIBs and Traps, and RMON Alarm Defaults
B-26
9783-A2-GB20-00July 2000
Table B-14. History OID Cross-Reference (3 of 5)
Object ID (OID)
1
MIB/TagItem
.1.3.6.1.4.1.1795.2.24.2.6.9.4 . . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.57.I .D Network Frames Dropped
Above CIR Within EIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRxFrNetDrop-
CirToEir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.59.I .D Network Frames Offered
Above EIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciOfferedFrOverEir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.61.I .D Network Frames Dropped
Above EIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRxFrNetDrop-
OverEir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.63.I .D DLCI EIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciEir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.2.1.2.I.D Inactive Seconds
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciStsInactiveSecs
.1.3.6.1.4.1.1795.2.24.2.6.9.4.3.1.5.I.D Average Latency
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyAvg
.1.3.6.1.4.1.1795.2.24.2.6.9.4.3.1.6.I.D Maximum Latency
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyMax
.1.3.6.1.4.1.1795.2.24.2.6.9.4.3.1.8.I.D Latency Packet Size
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyPacketSz
.1.3.6.1.4.1.1795.2.24.2.6.9.4.4.2 . . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.4.2.1.2.I.N Frame Size Upper Limit
(1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtFrameSzUpLimit
.1.3.6.1.4.1.1795.2.24.2.6.9.4.4.2.1.3.I.N Frame Size Count (1–5)
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtFrameSzCount
1
I = Interface ID of the frame relay link
D = DLCI number
N = Additional numeric index used by tables, like frame or burst size
H = Host control index
P = Protocol index
T = The time mask
