SNMP MIBs and Traps, and RMON Alarm Defaults
B-25
9783-A2-GB20-00
July 2000
Table B-14. History OID Cross-Reference (2 of 5)
Object ID (OID)
1
MIB/TagItem
.1.3.6.1.4.1.1795.2.24.2.6.9.4. . .
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.3.I.D DLCI CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciFrCIR
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.7.I .D Tx DEs
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciTxDE
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.8.I .D Tx BECNs
MIB:
pdn_FrExt.mib (E)
Tag:
devFrCircuitTxBECN
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.17.I.D Tx Frames Above CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciTxFrOutCIR
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.18.I.D Rx Frames Above CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRxFrOutCIR
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.20.I.D Network Frames Lost
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciNetDropFr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.22.I .D Rx DEs
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRxDE
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.37.I.D Network Frames Offered
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRmtOffFr
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.39.I.D Network Frames Offered
In CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRmtOffFrInCir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.41.I.D Network Frames Dropped
In CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciDropOffFrInCir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.43.I.D Network Frames Offered
Above CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRmtOffFrOutCir
.1.3.6.1.4.1.1795.2.24.2.6.9.4.1.1.45.I.D Network Frames Lost
Above CIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciRmtDropFrOutCir
.1.3.6.1.4.1.1795.2.24.2.6.9. 4.1.1.55.I .D Network Frames Offered
Above CIR Within EIR
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciDropFrCirToEir
1
I = Interface ID of the frame relay link
D = DLCI number
N = Additional numeric index used by tables, like frame or burst size
H = Host control index
P = Protocol index
T = The time mask
