SNMP MIBs and Traps, and RMON Alarm Defaults
B-24
9783-A2-GB20-00July 2000
Table B-14. History OID Cross-Reference (1 of 5)
Object ID (OID)
1
Item MIB/Tag
.1.3.6.1.2.1.2.2.1. . .
.1.3.6.1.2.1.2.2.1.5.I Link Speed
MIB:
MIB II (RFC 1573)
Tag:
ifSpeed
.1.3.6.1.2.1.2.2.1.10.I
All DLCI + LMI Rx Octets
MIB:
MIB II (RFC 1573)
Tag:
ifInOctets
.1.3.6.1.2.1.2.2.1.16.I All DLCI + LMI Tx Octets
MIB:
MIB II (RFC 1573)
Tag:
ifOutOctets
.1.3.6.1.2.1.2.10.32.2.1. . .
.1.3.6.1.2.1.10.32.2.1.4.I.D Rx FECNs
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedFECNs
.1.3.6.1.2.1.10.32.2.1.5.I.D Rx BECNs
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedBECNs
.1.3.6.1.2.1.10.32.2.1.6.I.D Tx Frames
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitSentFrames
.1.3.6.1.2.1.10.32.2.1.7.I.D Tx Octets
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitSentOctets
.1.3.6.1.2.1.10.32.2.1.8.I.D Rx Frames
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedFrames
.1.3.6.1.2.1.10.32.2.1.9.I.D Rx Octets
MIB:
FR DTE MIB (RFC 2115)
Tag:
frCircuitReceivedOctets
.1.3.6.1.4.1.1795.2.24.2. . .
.1.3.6.1.4.1.1795.2.24.2.6.9.4.7.1.16.I Rx Non-octet Aligns
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLinkRxNonOctet
1
I = Interface ID of the frame relay link
D = DLCI number
N = Additional numeric index used by tables, like frame or burst size
H = Host control index
P = Protocol index
T = The time mask
