SNMP MIBs and Traps, and RMON Alarm Defaults
B-22
9783-A2-GB20-00July 2000
Table B-11. DLCI Alarm Defaults – Paradyne Area (3 of 3)
Item
Falling
Threshold
Default
Rising
Threshold
Default
Event
Type
IntervalMIB/Tag/OID
2
Sample
Type
1
Tx Frames
Exceeding CIR
D
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciTxFrOutCIR
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.1.1.17.I.D
60 secs
(1 min)
None Must be
configured.
0
1
D = Delta. Indicates that the calculated difference between the current value and the previous value is contained
in the MIB.
A = Absolute. Indicates that the exact value for the item is contained in the MIB.
2
I in the OID = Interface ID of the frame relay link.
D = DLCI number.
