SNMP MIBs and Traps, and RMON Alarm Defaults
B-20
9783-A2-GB20-00July 2000
DLCI Alarm Defaults – Paradyne Area
These alarms apply to all DLCIs on the network interface and can be created
during RMON initialization or when a DLCI is created. They are put into the
Paradyne alarm area.
Table B-11. DLCI Alarm Defaults – Paradyne Area (1 of 3)
Item
Sample
Type
1
MIB/Tag/OID
2
Interval
Event
Type
Rising
Threshold
Default
Falling
Threshold
Default
Average Latency A
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyAvg
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.3.1.5.I.D
900 secs
(15 mins)
None Must be
configured.
0
Congested Seconds D
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciSts-
CongestedSecs
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.2.1.6.I.D
60 secs
(1 min)
Rising 5 5
Current Latency A
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtLatencyLatest
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.3.1.7.I.D
60 secs
(1 min)
None Must be
configured.
0
DLCI Inactive
Seconds
D
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciStsInactive-
Secs
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.2.1.2.I.D
900 secs
(15 mins)
Rising 1 1
Frames Dropped by
Network
D
MIB:
pdn_FrExt.mib (E)
Tag:
devFrExtDlciNetDropFr
OID:
.1.3.6.1.4.1.1795.2.24.2.
6.9.4.1.1.20.I.D
60 secs
(1 min)
Rising 1 1
Frames Received D
MIB:
FR DTE MIB
(RFC 2115)
Tag:
frCircuitReceivedFrames
OID:
.1.3.6.1.2.1.10.32.2.1.
8.I.D
60 secs
(1 min)
None Must be
configured.
0
1
D = Delta. Indicates that the calculated difference between the current value and the previous value is contained
in the MIB.
A = Absolute. Indicates that the exact value for the item is contained in the MIB.
2
I in the OID = Interface ID of the frame relay link.
D = DLCI number.
