Physical Interface Alarm Defaults
This alarm only applies to the FrameSaver DSL unit’s network interface.
Table B-9. Network Physical Interface Alarm Defaults
Item
Sample
Type
1
MIB/Tag/OID
2
Interval
Event
Type
Rising
Threshold
Default
Falling
Threshold
Default
Unavailable
Seconds
D
MIB:
pdn_FrExt.mib (E)
Tag:
pdnIfExtTotalUASs
OID:
.1.3.6.1.4.1.1795.2.24.2.6.-
12.1.1.1.4.I
900 secs
(15 mins)
Rising 1 1
1
D = Delta. Indicates that the calculated difference between the current value and the previous value is contained
in the MIB.
2
I in the OID = Interface ID of the frame relay link.
