SNMP MIBs and Traps, and RMON Alarm Defaults
B-14
9783-A2-GB20-00July 2000
Table B-7. enterprise-Specific Traps and Variable-Bindings (3 of 3)
Trap Possible CauseVariable-Bindings
enterpriseTest-
Start(5)
For physical interfaces and
frame relay links:
H ifIndex (RFC 1573)
H .0.0 (placeholder)
H devLastTrapString
(devHealthAndStatus.-
mib
F i t l i it (DLCI )
At least one test has been
started on an interface or virtual
circuit.
String:
‘$testString test started on
$ifString.’ (e.g., ‘DTE Loopback
test started on Sync Data Port
S01P1.’)
enterpriseTest-
Stop(105)
For virtual circuits (DLCIs):
H devFrExtDlciIfIndex
(devFrExt.mib)
H devFrExtDlciDlci
(devFrExt.mib)
H devLastTrapString
(devHealthAndStatus.-
mib
All tests have been halted on an
interface or virtual circuit.
String:
‘$testString test stopped on
$ifString.’ (e.g., ‘Disruptive PVC
Loopback test stopped on
DLCI 100 of Sync Data Port
S01P1 frame relay.’)
enterpriseLinkSpeed
Change(14)
H ifIndex (RFC 1573)
H ifSpeed (RFC 1573)
H devLastTrapString
(devHealthAndStatus.-
mib
The link speed has changed.
String:
’Speed on $ifName changed to
$ifSpeed bps.’
